Efficient dredging operations require well-coordinated dredging machines, clear dredging manuals, and detailed dredging method statements. Choosing the right dredging methods and equipment ensures safety, efficiency, and compliance with project standards. The HPP 150-350 Atlantic Hydraulic Power Pack from Atlantic Hydraulic Power is a versatile solution that powers a wide range of dredging machinery and hydraulic tools with precision and reliability.
This multi-functional hydraulic power pack is ideal for projects that involve submersible pumps, concrete crushers, drills, and other heavy-duty hydraulic tools.
Multi-Functional Hydraulic Power for Dredging Machines
The Atlantic HPP 150-350 is designed to support a wide range of dredging equipment, enabling operators to apply various dredging methods effectively:
Submersible water pumps for slurry removal
Concrete crushers for site preparation
Cut-off and diamond chain saws for underwater or confined work
Disc saws, rock drills, and core drills for precision excavation
Air compressors and power generators for auxiliary hydraulic tools
Its flexibility allows operators to implement multiple dredging methods, from suction dredging to excavation-based dredging, using a single power unit.
Hydraulic Configurations
The HPP 150-350 offers customizable hydraulic setups to meet different dredging needs:
Single hydraulic circuit: One gear pump for powering a single tool
Dual hydraulic circuits: Two gear pumps for parallel operations or combined flow for single high-demand tools
High-pressure piston pump: Suitable for applications above 210 bar
Remote control options: Multiple configurations for safer and easier operation
These configurations ensure that dredging teams can apply different methods efficiently, with consistent power delivery.
Technical Specifications
Specification HPP 150 - 350
Oil Flow 2 x 75 LPM = 150 LPM
Max. Pressure 350 bar
Prime Mover Deutz TCD 3.6, 4-cylinder Inline
Engine Speed Fixed Speed – 1800 rpm
Engine Power 70 kW – 100 kW
Hydraulic Circuits Double hydraulic circuit with twin piston pumps
Dimensions (L x W x H) 2,250 x 1,350 x 2,400 mm
Weight 2,000 kg
These robust specifications make the HPP 150-350 suitable for demanding dredging projects and multiple equipment setups.
Applications in Dredging Projects
Using the HPP 150-350, operators can implement a variety of dredging methods:
Suction dredging: For sediment removal in rivers, lakes, and harbors
Excavation dredging: For removing compacted material or rocks
Beach and coastal maintenance: Sand replenishment and erosion control
Industrial and civil projects: Dam cleaning, pond maintenance, and slurry pumping
With the support of a detailed dredging manual and a clear method statement, teams can ensure safe and efficient operations across all project types.
Why Choose Atlantic Hydraulic Power Pack HPP 150-350?
Multi-functional hydraulic power for various dredging equipment
High-pressure and high-flow performance for demanding tasks
Portable and flexible setup for multiple dredging methods
Remote control capability for safer operations
Durable and reliable construction for long-term industrial and marine use
For contractors and dredging operators seeking versatile equipment to power dredging machines and execute precise dredging methods, the HPP 150-350 is a proven and dependable solution.
