The Atlantic ASP 500 E Screed Pump is a high-performance electric pneumatic conveyor engineered for the preparation and conveying of sand, floor screed, gravel, mortar, and fine-grained concrete. Designed with German engineering, the ASP 500 E combines high productivity, reliable performance, and simple operation, making it the ideal solution for flooring contractors, civil engineering companies, and construction professionals throughout Abu Dhabi, Dubai, Sharjah, the UAE, and the Middle East. It is designed to be powered by an external 700 CFM air compressor for efficient long-distance conveying.
Key Features
German-engineered electric pneumatic conveyor
High-capacity 650-litre mixing vessel
500-litre operating volume
Productivity up to 10 m³/hour
Handles materials with a maximum grain size of 32 mm
Delivery distance up to 150 m horizontally and 80 m vertically
Powerful 18.5 kW electric motor
Forced agitation system with wear-resistant steel blades
Large pressure vessel for continuous material flow
Easy operation and maintenance
Durable construction for demanding construction environments
Requires an external 700 CFM air compressor for optimal performance
Technical Specifications
Specification Value
Mixer Vessel Capacity 650 Litres
Operating Capacity 500 Litres
Maximum Output 10 m³/hour
Maximum Grain Size 32 mm
Horizontal Delivery Distance 150 m
Vertical Delivery Distance 80 m
Electric Motor 18.5 kW
Dimensions (L × W × H) 3680 × 1600 × 1300 mm
Weight 1125 kg
Air Compressor Requirement 700 CFM External Compressor
Applications
The Atlantic ASP 500 E is ideal for:
Floor Screeding
Sand Transfer
Sand-Cement Screed
Mortar Pumping
Fine-Grained Concrete Pumping
Gravel Conveying
Lightweight Concrete
Underfloor Heating Screeds
Residential Buildings
Commercial Towers
Industrial Flooring
Warehouses
Infrastructure Projects
Civil Engineering
Marine Construction
Advantages
High conveying capacity
Long pumping distances
Continuous and uniform material flow
Reduced labour costs
Increased productivity
Low maintenance requirements
Reliable heavy-duty operation
Wear-resistant mixing blades
Efficient electric drive
Suitable for demanding construction projects
