If you're looking to buy an MX-10 Mixer Pump for demanding refractory shotcrete or pump cast applications, choosing equipment with proven reliability is essential. The MX-10 Mixer/Pump has been the industry standard for monolithic refractory installations since 1996, offering exceptional pumping power, fast mixing, and heavy-duty construction for industrial projects around the world.
Whether you're expanding your fleet or replacing older equipment, understanding the MX-10 Mixer Pump price, features, and capabilities will help you make an informed investment.
Why Buy the MX-10 Mixer Pump?
The MX-10 is engineered for contractors who need a dependable solution for pumping dense refractory materials. Combining a 2200 lb. hydraulic pan mixer with a 2200 PSI ultra-high-pressure swing tube pump, it delivers consistent performance even in the most demanding environments.
Key advantages include:
Pumps dense refractory materials over 300 feet vertically
Produces up to 10 tons of material per hour
Fast 1.5–2 minute mixing cycles
Heavy-duty industrial construction
Easy maintenance with a swing-out receiving hopper
Excellent return on investment
These capabilities make the MX-10 an ideal choice for power plants, cement plants, steel mills, petrochemical facilities, and other industrial refractory projects.
High-Performance Mixing and Pumping
The MX-10 combines two critical systems into one efficient machine:
Hydraulic Pan Mixer
The 2200 lb. capacity hydraulic pan mixer delivers fast, uniform mixing for dense refractory materials. Its high-torque hydraulic drive ensures every batch reaches the proper consistency before pumping begins.
Ultra High-Pressure Pump
The 3-inch × 24-inch swing tube pump generates 2200 PSI pumping pressure, allowing material to be transported over long horizontal and vertical distances with reliable flow.
This combination increases productivity while reducing labor requirements and project downtime.
Built for Productivity
Every component of the MX-10 is designed to maximize efficiency on the job site.
Features include:
2200 PSI piston face pressure
2200 lb. capacity hydraulic pan mixer
2,500 lb. swing-out receiving hopper
Hydraulic agitator for continuous material flow
Fill Rite water meter
20-gallon dousing bucket
Reliable solid-state electronics
CE Certification
The swing-out hopper provides quick access to the swing tube assembly, making routine cleaning and maintenance faster and easier.
Flexible Power Options
The MX-10 can be configured to suit different operating environments with several power choices:
John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors
This flexibility allows contractors to select the best configuration for indoor or outdoor industrial applications.
Optional Upgrades
Customize your MX-10 with factory-installed options such as:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Wireless or pendant remote control
Spare tire
Skid-mounted version with forklift tubing
These upgrades improve convenience, simplify maintenance, and enhance job site productivity.
MX-10 Mixer Pump Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2200 PSI
Mixer 2200 lb. Capacity Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Hopper 2,500 lb. Swing-Out Receiving Hopper with Hydraulic Agitator
Discharge 3 inches
Operating Platform 22 sq. ft.
Trailer Dual 6,000 lb. Axles with Electric Brakes
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
MX-10 Mixer Pump Price
If you're researching the MX-10 Mixer Pump price, it's important to know that the final cost depends on several factors, including:
Selected engine configuration (diesel or electric)
Optional accessories and upgrades
Remote control options
Skid-mounted or trailer-mounted configuration
Shipping destination and delivery requirements
Because every project has different requirements, the best way to obtain accurate pricing is to request a personalized quote based on your preferred configuration and location.
Why Contractors Choose the MX-10
Contractors worldwide continue to buy the MX-10 because it offers:
Proven performance since 1996
High-pressure pumping for demanding refractory applications
Fast, consistent mixing
Easy maintenance and cleaning
Rugged construction for industrial use
Multiple power options
Worldwide customer support
Strong long-term value and return on investment
