2200 LB Pan Mixer – Heavy-Duty Industrial Mixing Solution
The 2200 LB Pan Mixer is a powerful electric powered hydraulic pan mixer designed for demanding refractory and industrial mixing applications. Built as a large capacity industrial refractory mixer, this equipment is engineered to mix up to 1 metric ton of refractory castable while delivering consistent, high-quality results.
Featuring a reliable hydrostatic drive system and heavy-duty planetary gearbox, the mixer provides excellent torque and efficient operation. With typical mixing times of 1.5 to 2 minutes, the 2200 LB Pan Mixer helps improve productivity during monolithic refractory installation, furnace repair, kiln maintenance, and other industrial projects.
Advanced Electric Hydraulic Mixing Performance
The electric-powered hydraulic system provides smooth and dependable operation while maintaining consistent mixing performance. The heavy-duty planetary gearbox ensures efficient power transfer, allowing the mixer to process dense refractory materials with excellent uniformity.
Designed for professional contractors and industrial facilities, this large-capacity mixer delivers the durability needed for continuous heavy-duty use.
Features of the 2200 LB Pan Mixer
1.5 to 2 Minute Mix Time for fast production cycles
2200-Pound Hydraulic Pan Mixer with Bottom Discharge
Large capacity design for mixing up to 1 metric ton of refractory castable
Electric-powered hydraulic operation for reliable performance
Heavy-duty planetary gearbox for consistent mixing torque
Fill-Rite Water Meter for precise water addition
20-gallon dousing tank for rapid water introduction
Forklift pickup points for easy transportation
Operator platform with guard rails and ladder for safe operation
Telescoping adjustable legs for flexible setup
Efficient Bottom Discharge System
The bottom discharge design allows operators to quickly remove mixed refractory material, reducing downtime between batches. This feature improves workflow efficiency for applications where accurate material placement and fast production are required.
The 2200 LB Pan Mixer is ideal for projects that require dependable mixing performance and consistent refractory material preparation.
Electric Power Configuration
The standard power system includes:
40 HP electric motor with starter and disconnect
This electric drive configuration provides reliable power for industrial environments where clean and efficient operation is required.
Available Options
The mixer can be customized with additional features, including:
Hydraulic discharge chute
Separately mounted power supply
Hydraulic leg adjustment
2,000 PSI hydraulic pressure washer
Three height discharge adjustment settings
Technical Specifications
Specification Details
Equipment Type Electric Powered Hydraulic Pan Mixer
Capacity 2200 LB
Application Refractory Castable Mixing
Mixing Capacity Up to 1 Metric Ton
Mix Time 1.5–2 Minutes
Weight 4,500 lbs.
Length 120 inches
Width 72 inches
Height (Down Position) 82 inches
Height (Raised Position) 103 inches
Material Discharge Height (Down Position) 52 inches
Material Discharge Height (Raised Position) 72 inches
Applications of the 2200 LB Pan Mixer
The 2200 LB Pan Mixer is designed for a variety of industrial applications, including:
Monolithic refractory installation
Furnace lining construction and repair
Kiln repair projects
Steel plant refractory maintenance
Cement plant mixing applications
Thermal processing equipment projects
Industrial refractory castable preparation
Reliable Large Capacity Industrial Refractory Mixing Equipment
The 2200 LB Pan Mixer combines electric hydraulic power, planetary gearbox technology, and high-capacity mixing performance to support demanding industrial operations. Its durable construction and efficient mixing system make it a dependable choice for professionals requiring consistent refractory material quality and increased jobsite productivity.
Electric Powered Hydraulic Pan Mixer for Large-Scale Refractory Applications
