RMX-5000 High Capacity Shotcrete Machine for Professional Construction Projects
The High Capacity Shotcrete Machine is designed for contractors who need powerful, reliable, and efficient equipment for large-scale shotcrete, concrete, and refractory applications. The RMX-5000 Mixer/Pump delivers exceptional pumping performance with an ultra high-pressure 3-inch swing tube system combined with advanced hydraulic mixing technology.
Built for demanding construction environments, the RMX-5000 provides consistent material flow, high-pressure pumping capability, and dependable operation for projects requiring high productivity and precision.
Powerful High Capacity Shotcrete Pumping Performance
The RMX-5000 is engineered as a heavy-duty shotcrete machine capable of handling challenging applications where reliable material delivery is essential.
Its advanced pumping system provides:
2,200 PSI piston face pressure
High-pressure shotcrete placement capability
0–5 cubic yards per hour output capacity
Long-distance pumping performance
Consistent material delivery
The RMX-5000 is ideal for contractors working on large construction, mining, tunneling, and industrial projects.
Ultra High Pressure 3-Inch Swing Tube Pump System
At the heart of the RMX-5000 is a 3" x 18" ultra high-pressure swing tube pump designed for demanding shotcrete operations.
Pump Features
Pump pressure up to 2,200 PSI
3-inch side discharge outlet
Designed for refractory shotcrete applications
Suitable for dense conventional shotcrete
Reliable performance during continuous operation
The swing tube pump design helps provide smooth pumping and efficient material transfer across various job-site conditions.
High Capacity Hydraulic Mixing System
A high capacity shotcrete machine requires a powerful mixing system to maintain consistent material quality. The RMX-5000 offers advanced hydraulic mixer options for different applications.
1,000 lb. Hydraulic Paddle Mixer
The hydraulic paddle mixer with planetary gearbox drive is designed for:
Refractory applications
Dense shotcrete materials
Industrial repair projects
Specialty construction mixtures
This mixing system ensures proper material blending and supports reliable pumping performance.
1,000 lb. Hydraulic Spiral Mixer
The hydraulic spiral mixer is suitable for:
Conventional shotcrete applications
Plaster materials
Stucco pumping
Cement-based mixtures
The spiral mixing system provides flexibility for contractors handling multiple material types.
Applications of RMX-5000 High Capacity Shotcrete Machine
The RMX-5000 is designed for a wide range of demanding industries and construction applications.
Common uses include:
Large-scale shotcrete projects
Tunnel construction
Mining support applications
Underground construction
Refractory installation
Concrete repair
Structural reinforcement
Industrial maintenance
Stucco and plaster pumping
Infrastructure development
Its high capacity design makes it suitable for projects requiring dependable production and efficient material placement.
RMX-5000 High Capacity Shotcrete Machine Features
The RMX-5000 includes advanced features focused on performance, durability, and easy operation.
Standard Features
Ultra high-pressure 3-inch swing tube pump
2,200 PSI piston face pressure
1,000 lb. hydraulic paddle mixer
Planetary gearbox drive for refractory applications
1,000 lb. hydraulic spiral mixer option
Hydraulic receiving hopper lift
Easy access to swing tube section for cleaning and maintenance
Fill Rite water meter
3-inch HD side discharge
Reliable solid-state electronics
CE Certification
RMX-5000 Technical Specifications
Specification Details
Pump Type 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer Capacity 1,000 lb.
Output Capacity 0–5 Cubic Yards Per Hour
Discharge 3" Side Discharge
Hopper Capacity 1,200 lb. Receiving Hopper with Hydraulic Agitator
Trailer Single 6,000 lb. Capacity Axle with Electric Braking and Lights
Dimensions 165" x 76" x 63"
Weight 5,000 lbs
Power Options for RMX-5000
The RMX-5000 high capacity shotcrete machine is available with different power configurations to meet various project requirements.
Available power options include:
Kubota V3600 66 HP water-cooled diesel engine
50 HP electric motor
These options allow contractors to select the ideal power source for remote construction sites, industrial facilities, and stationary applications.
Optional Equipment for Increased Productivity
The RMX-5000 can be equipped with additional accessories to improve operation and maintenance efficiency.
Available options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2-inch flow meter
Spare tire mounted
Pendant remote control
Wireless remote control
Skid-mounted design with forklift tubing
Benefits of Using a High Capacity Shotcrete Machine
A high capacity shotcrete machine helps contractors improve efficiency and achieve consistent material application.
Key benefits include:
Increased shotcrete production capability
High-pressure material placement
Reliable hydraulic mixing performance
Reduced manual labor requirements
Improved project efficiency
Flexible application options
Durable construction for demanding environments
Why Choose RMX-5000 High Capacity Shotcrete Machine?
The RMX-5000 Mixer/Pump provides contractors with a complete solution for high-performance shotcrete and pumping applications. Its combination of a powerful swing tube pump, hydraulic mixing technology, and flexible power options makes it suitable for demanding construction and industrial projects.
For tunnel construction, mining operations, refractory work, and large-scale concrete applications, the RMX-5000 delivers the reliability, capacity, and performance required for professional results.
High Capacity Shotcrete Machine RMX-5000 Advanced Mixer Pump for Heavy-Duty Applications
