The RMX5000 Mixer / Pump is a powerful and versatile pumping solution designed for demanding construction, refractory, shotcrete, stucco, and plaster applications. Built for contractors who require dependable performance, the RMX-5000 combines an ultra-high-pressure swing tube pump with advanced hydraulic mixing technology to deliver consistent material placement over long distances.
Designed for extreme job site conditions, the RMX5000 provides excellent pumping force, efficient mixing capability, and easy maintenance features for professional applications.
RMX-5000 Mixer / Pump Features
Ultra High-Pressure Pump System
The RMX5000 features a 3-inch x 18-inch ultra high-pressure swing tube pump with 2200 PSI piston face pressure. This powerful pumping system is designed for:
Refractory shotcrete applications
Dense conventional shotcrete
Long-distance material pumping
Industrial construction projects
1000 lb Capacity Paddle Mixer
For refractory applications, the RMX-5000 includes a 1000 lb capacity hydraulic paddle mixer with a planetary gearbox drive. This heavy-duty mixer provides strong material blending performance and helps maintain consistent mix quality during operation.
1000 lb Capacity Spiral Mixer
The integrated 1000 lb capacity hydraulic spiral mixer is designed for conventional shotcrete and plaster applications. This provides flexibility for contractors working with different construction materials.
Hydraulic Receiving Hopper Lift
The hydraulic receiving hopper lift allows quick and convenient access to the swing tube section for cleaning and maintenance. This feature improves service efficiency and helps reduce downtime on busy job sites.
Reliable Operating Features
The RMX5000 includes several features designed for professional performance:
Fill Rite water meter for precise water control
3-inch HD side discharge
Reliable solid-state electronics
CE certification
RMX-5000 Technical Specifications
Pump Specifications
Pump Type: 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure: 2,200 PSI
Mixer Specifications
Paddle Mixer: 1,000 lb capacity hydraulic paddle mixer
Spiral Mixer: 1,000 lb capacity hydraulic spiral mixer
Output Capacity
Output: 0–5 cubic yards per hour
Hopper and Discharge
Hopper Capacity: 1,200 lb receiving hopper with hydraulic agitator
Discharge: 3-inch side discharge
Trailer Specifications
Trailer: Single 6,000 lb capacity axle
Braking System: Electric braking with lights
Dimensions and Weight
Dimensions: 165" x 76" x 63"
Weight: Approximately 5,000 lbs
RMX5000 Power Options
The RMX5000 is available with different power configurations to match various working environments.
Kubota Diesel Engine Option
Kubota V3600
66 HP water-cooled diesel engine
The diesel configuration provides reliable operation for remote locations and demanding construction sites.
Electric Motor Option
50 HP electric motor
The electric version is suitable for facilities and job sites where electrical power is readily available.
Available RMX-5000 Options
To improve productivity and convenience, additional equipment options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2-inch flow meter
Spare tire mounting
Pendant or wireless remote control
Skid-mounted design with forklift tubing
RMX5000 Applications
The RMX-5000 Mixer / Pump is suitable for a wide range of professional applications, including:
Refractory installation
Shotcrete spraying
Stucco pumping
Plaster applications
Tunnel construction
Mining projects
Industrial repair work
Concrete placement
Why Choose RMX5000 Mixer / Pump?
The RMX5000 is designed for contractors who need a dependable machine capable of handling challenging pumping and mixing operations. Its combination of high-pressure pumping capability, large-capacity mixers, hydraulic features, and durable construction makes it a reliable choice for demanding industrial and construction applications.
RMX5000 Mixer / Pump High Performance Ultra-Pressure Mixing and Pumping Equipment
