Finding the right grout pump for sale is important for contractors who need reliable material delivery, controlled pumping speed, and equipment suitable for demanding grouting applications. For hot epoxy grouting contractors who already have compatible hydraulic power units, the Blastcrete D3522 Attachment provides a practical hydraulic-powered pumping solution.
The D3522 is designed to couple to a hydraulic power unit and provides variable-speed pumping from 0 to 6 cubic yards per hour, with pumping pressure of up to 400 PSI.
For contractors searching for a hydraulic grout pump for sale, the D3522 offers a straightforward design based on a 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox.
D3522 Hydraulic Grout Pump Attachment
The D3522 Attachment is designed for hot epoxy grouting contractors who already own suitable hydraulic power equipment.
Instead of operating as a standalone engine-driven pump, the attachment uses a compatible hydraulic power unit as its power source.
This configuration can be useful for contractors who want to expand their existing equipment fleet while continuing to use their available hydraulic power equipment.
Grout Pump for Sale for Hot Epoxy Applications
When evaluating a grout pump for sale, contractors should consider the type of grout being pumped, required flow rate, pumping pressure, power source, and jobsite requirements.
The D3522 is specifically designed for hot epoxy grouting applications and provides variable-speed pumping from:
0–6 cubic yards per hour
This range gives contractors the ability to adjust pumping output within the equipment's rated capacity.
Before purchasing a grout pump, always confirm that the intended grout or epoxy material is compatible with the equipment and pumping tubes.
Hydraulic Grout Pump for Sale With 400 PSI Capability
The D3522 provides up to 400 PSI pumping pressure.
This capability can support compatible professional grouting applications where controlled pumping pressure is required.
The maximum rated pressure should not be interpreted as the required operating pressure for every project. Contractors should determine the appropriate operating pressure based on the material, application, project specifications, and equipment requirements.
2-Inch Hydraulic Squeeze Pump
The D3522 uses a 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox.
The squeeze-pump design provides a simple approach to moving compatible grout materials through the pumping system.
For contractors comparing a hydraulic grout pump for sale, the 2-inch pump configuration and rated output capacity are important specifications to consider when matching equipment to project requirements.
Heavy-Duty Planetary Gearbox
The pump is driven by a heavy-duty planetary gearbox.
The gearbox provides the mechanical drive for the squeeze-pump mechanism and contributes to the equipment's heavy-duty configuration.
For industrial and construction contractors, a durable drive system can be an important factor when selecting pumping equipment for regular professional use.
Epoxy Material Does Not Contact Moving Parts
One notable feature of the D3522 design is that epoxy material does not come into contact with the moving parts of the pump.
Keeping the material separate from moving mechanical components can be an important consideration when evaluating hot epoxy pumping equipment.
Proper maintenance and inspection should still be performed according to the manufacturer's recommendations.
Long-Lasting Pumping Tubes
The D3522 incorporates long-lasting pumping tubes.
Pumping tubes are essential wear components in a squeeze-pump system. Contractors should inspect tubes regularly and replace them when required according to applicable maintenance guidelines.
Proper maintenance can help support consistent pumping performance throughout the equipment's service life.
Hydraulic Requirements
Before purchasing a hydraulic grout pump for sale, contractors should verify the hydraulic requirements of the equipment.
The D3522 requires:
10 GPM @ 3,000 PSI
The existing hydraulic power unit should be checked to ensure that it can provide the specified flow and pressure.
Properly matching the hydraulic power source with the attachment is important for operating the pump within its intended specifications.
D3522 Specifications
Specification D3522 Attachment
Pump Type 2" Hydraulic Squeeze Pump
Drive System Heavy-Duty Planetary Gearbox
Output Capacity 0–6 cubic yards per hour
Maximum Pumping Pressure Up to 400 PSI
Hydraulic Requirement 10 GPM @ 3,000 PSI
Length 76"
Width 37"
Height 39"
Hopper Charging Height 28"
Benefits of the D3522
Variable-Speed Pumping
The D3522 provides an output range of 0–6 cubic yards per hour, allowing contractors to adjust pumping speed according to compatible application requirements.
Hydraulic-Powered Operation
The attachment connects to a compatible hydraulic power unit, making it suitable for contractors who already own hydraulic equipment.
400 PSI Pumping Capability
The D3522 provides up to 400 PSI pumping pressure.
Simple Pumping System
The 2-inch hydraulic squeeze pump provides a straightforward material delivery system.
Heavy-Duty Drive
The planetary gearbox provides the mechanical drive required for the pump.
Material Separation
Epoxy material does not contact the moving pump components.
Long-Lasting Pumping Tubes
The system uses long-lasting pumping tubes designed for professional pumping applications.
What to Consider When Buying a Grout Pump
If you are searching online for a grout pump for sale, consider the following factors before making a purchase.
Pumping Capacity
Determine the amount of grout that must be delivered per hour. The D3522 offers a rated capacity of 0–6 cubic yards per hour.
Pumping Pressure
Check the pressure requirements of your application. The D3522 provides up to 400 PSI.
Hydraulic Compatibility
Confirm that your hydraulic power unit can supply 10 GPM at 3,000 PSI.
Material Compatibility
Verify that the grout or epoxy material is compatible with the pump and pumping tubes.
Physical Dimensions
Consider transportation and jobsite access. The D3522 measures 76 inches long, 37 inches wide, and 39 inches high.
Maintenance
Review maintenance requirements for pumping tubes, hydraulic components, and other wear parts before purchasing equipment.
Applications for the D3522
The D3522 is designed for hot epoxy grouting contractors. Depending on material compatibility and project requirements, potential applications can include:
Hot epoxy grouting
Industrial grouting
Structural grouting
Concrete repair
Equipment grouting
Machinery base grouting
Construction grouting
Industrial maintenance
Concrete crack repair
Foundation grouting
Professional epoxy pumping
Contractors should always verify the suitability of the equipment and material for a specific application.
D3522 Dimensions
The D3522 has the following dimensions:
Length: 76 inches
Width: 37 inches
Height: 39 inches
Hopper charging height: 28 inches
These dimensions should be considered when planning transportation, storage, equipment positioning, and hopper loading at the jobsite.
Why Choose a Hydraulic Grout Pump?
A hydraulic grout pump can be an attractive option for contractors who already own a compatible hydraulic power unit.
The D3522 uses existing hydraulic power to operate its squeeze-pump system. This allows contractors to add hot epoxy pumping capability to their equipment lineup while using a compatible hydraulic power source.
Its variable-speed output and pressure capability provide flexibility for compatible professional grouting applications.
D3522 for Contractors Looking for a Grout Pump for Sale
For contractors searching for a grout pump for sale, the D3522 offers a specialized solution for hot epoxy grouting.
The combination of:
0–6 cubic yards per hour output
Up to 400 PSI pumping pressure
2-inch hydraulic squeeze pump
Heavy-duty planetary gearbox
10 GPM @ 3,000 PSI hydraulic requirement
Long-lasting pumping tubes
No epoxy contact with moving pump parts
makes the D3522 an option to consider when selecting professional hot epoxy grouting equipment.
Contractors should verify their hydraulic power unit and intended grout material before purchase and operation.
Request Information About the D3522
Contractors interested in purchasing or obtaining pricing information can use the provided resources.
Request a Quote
Download the D3522-A Brochure
Conclusion
The Blastcrete D3522 Attachment provides a hydraulic-powered solution for contractors working with compatible hot epoxy grout applications.
With variable-speed pumping from 0 to 6 cubic yards per hour and up to 400 PSI pumping pressure, the D3522 offers controlled material delivery through a 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox.
For contractors searching for a grout pump for sale or hydraulic grout pump for sale, the D3522 is worth evaluating when an existing compatible hydraulic power unit is available.
Its hydraulic-powered design, long-lasting pumping tubes, and separation of epoxy material from moving pump components provide useful features for professional hot epoxy grouting operations.
