A reliable gypsum flooring mixer pump can help contractors streamline field batching, mixing, and pumping operations. The D6528 Mixer/Pump is designed for field batching and pumping up to 12 cubic yards per hour, making it a practical equipment solution for professional gypsum flooring applications.
The D6528 combines a 9 cubic foot hydraulic spiral mixer, a 12 cubic foot receiving hopper, and a 3-inch hydraulic squeeze pump in one integrated machine. Its variable-speed pumping system provides output from 0 to 12 cubic yards per hour.
D6528 Gypsum Flooring Pump
The D6528 is designed as a combined mixer and pump for field applications. Its 9 cubic foot hydraulic spiral mixer prepares material before hydraulically dumping it into the 12 cubic foot receiving hopper.
A hydraulic agitator in the receiving hopper helps move the mixed material toward the pump. The material is then delivered through the D6528's 3-inch hydraulic squeeze pump.
The pump provides variable-speed operation from 0 to 12 cubic yards per hour.
Gypsum Flooring Mixer Pump for Field Applications
Gypsum flooring projects often require equipment capable of preparing and transporting material efficiently. The D6528 integrates mixing and pumping into a single machine.
The system includes:
9 cubic foot hydraulic spiral mixer
Hydraulic mixer dump
12 cubic foot receiving hopper
Hydraulic hopper agitator
3-inch hydraulic squeeze pump
Variable-speed pumping
Up to 12 cubic yards per hour output
This integrated design provides a single equipment platform for field batching and pumping.
9 Cubic Foot Hydraulic Spiral Mixer
The D6528 features a 9 cubic foot hydraulic spiral mixer equipped with a hydraulic dump and clean-out door.
The hydraulic dump allows mixed material to move into the receiving hopper after the batching process. The clean-out door provides access for equipment cleaning and maintenance.
The hydraulic design helps connect material mixing directly with the pumping operation.
12 Cubic Foot Receiving Hopper
After mixing, material is transferred into the D6528's 12 cubic foot receiving hopper.
The hopper is equipped with a hydraulic agitator that helps maintain material movement before pumping.
The hopper provides a dedicated transition point between the 9 cubic foot mixer and the 3-inch hydraulic squeeze pump.
3-Inch Hydraulic Squeeze Pump
The D6528 uses a 3-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox.
Its variable-speed system provides an output range of 0 to 12 cubic yards per hour.
For gypsum flooring applications, contractors can select the appropriate pumping rate according to project requirements and material conditions.
Why Use a Gypsum Flooring Pump?
A dedicated gypsum flooring pump can provide an integrated approach to material handling by combining mixing and pumping capabilities.
The D6528 is designed to provide:
Field batching capability
Hydraulic material mixing
Hydraulic mixer dumping
Receiving-hopper agitation
Controlled material pumping
Variable-speed output
Up to 12 cubic yards per hour capacity
Contractors should always verify that the machine configuration is suitable for the specific gypsum material and flooring system being installed.
D6528 Gypsum Flooring Applications
The D6528 is a popular solution for gypsum flooring applications.
Its combination of hydraulic mixing and pumping allows material to be prepared in the field and transported through the pumping system to the application area.
The machine can be configured with either diesel or electric power, depending on job-site requirements.
D6528 Specifications
Specification Details
Model D6528 Mixer/Pump
Output Capacity 0-12 cubic yards per hour
Mixer Capacity 9 cubic feet
Receiving Hopper 12 cubic feet
Pump 3-inch hydraulic squeeze pump
Length 204 inches
Width 88 inches
Water Tank Height 89 inches
Mixer Height, Dump Position 86 inches
Charging Height 48 inches
D6528 Power Options
The D6528 gypsum flooring mixer pump is available with two power options.
Kubota Diesel Power
Kubota V1505
29 HP
Water-cooled diesel
Electric Power
30 HP electric motor
Starter and disconnect
The appropriate power configuration depends on the available job-site power and operating requirements.
D6528 Equipment Options
Additional options are available for different project requirements:
Pendant or wireless remote
150-gallon water tank with 2-inch flow meter
Mounted spare tire
Hydraulic pressure washer
Dual axles
Mounted air compressor
Contractors can select options according to transportation, water supply, cleaning, and operational needs.
Benefits of the D6528 Gypsum Flooring Mixer Pump
The D6528 provides an integrated solution for gypsum flooring contractors who require field batching and pumping capabilities.
Key characteristics include:
Up to 12 cubic yards per hour output
9 cubic foot hydraulic mixer
12 cubic foot receiving hopper
3-inch hydraulic squeeze pump
Variable-speed material delivery
Hydraulic hopper agitation
Diesel or electric power
Optional remote controls
Optional water tank and pressure washer
Selecting a Gypsum Flooring Pump
Before purchasing a gypsum flooring pump, contractors should evaluate the complete equipment configuration.
Output Capacity
Determine the required production rate. The D6528 provides output from 0 to 12 cubic yards per hour.
Mixer Capacity
The machine uses a 9 cubic foot hydraulic spiral mixer.
Hopper Capacity
The receiving hopper provides 12 cubic feet of capacity.
Pump Configuration
The D6528 uses a 3-inch hydraulic squeeze pump with variable-speed operation.
Power Requirements
Choose the diesel or electric configuration according to the job-site environment.
Transportation
The D6528 measures 204 inches long and 88 inches wide. Transportation and job-site access should be considered before purchase.
D6528 for Professional Gypsum Flooring
The D6528 gypsum flooring mixer pump combines field batching, hydraulic mixing, material receiving, and pumping into one integrated machine.
With output up to 12 cubic yards per hour, the D6528 is designed for professional applications where controlled material mixing and delivery are important.
For contractors comparing gypsum flooring equipment, reviewing the machine's specifications, power options, and accessories can help determine whether the D6528 is appropriate for the project.
