The Shotcrete Machine plays an important role in modern concrete construction, repair, mining, tunneling, and other projects where concrete must be efficiently placed on challenging surfaces. For contractors working with dry mix applications, the Dry Process Shotcrete Machine provides an effective method for preparing and delivering shotcrete material.
The Blastcrete Multi-Rig is an integrated system designed for field batching concrete sand and cement for dry process shotcrete applications. It combines a high-capacity pan mixer, rubber belt conveyor, and rotary gunite machine into one mobile unit.
What Is the Blastcrete Multi-Rig?
The Multi-Rig is designed to simplify the production and delivery of dry process shotcrete material directly at the jobsite. Its integrated system allows contractors to batch concrete sand and cement, mix the materials, and transfer them to a rotary gunite machine for application.
The system features a 1,500 lb. capacity hydrostatic pan mixer. The mixer can be loaded using a skid steer, helping make material handling more convenient at the jobsite.
Once loaded, the materials are blended in approximately 1.5 to 2 minutes. The mixed material is then discharged through the bottom slide door onto the rubber belt conveyor.
Efficient Dry Process Shotcrete Machine
A major advantage of a Dry Process Shotcrete Machine is its ability to support efficient material handling for shotcrete applications. In the Blastcrete Multi-Rig, the conveyor transfers the prepared material directly to the rotary gunite machine.
The rotary gunite machine offers variable-speed operation from 0 to 6 tons per hour. This allows operators to adjust the output according to project requirements and application conditions.
The integrated design of the Multi-Rig helps reduce the need for separate material-processing equipment and creates a more organized workflow for field shotcrete operations.
Key Features of the Shotcrete Machine
The Blastcrete Multi-Rig includes several features designed for demanding construction environments:
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable output from 0–6 tons per hour
Mixer tilt function for easier cleanup
Trailer-mounted configuration
Dual electric braking axles and lights
29 HP Kubota V1505 water-cooled diesel power
These features make the Multi-Rig Shotcrete Machine a practical option for contractors requiring mobile dry process shotcrete equipment.
Multi-Rig Specifications
The Blastcrete Multi-Rig is built as a trailer-mounted system for field use.
Technical Specifications
Specification Details
Output 0–6 tons per hour
Mixer Capacity 1,500 lbs.
Mounting Trailer mounted
Axles Dual electric braking axles
Dimensions 249" × 76" × 72"
Weight 7,000 lbs.
Engine Kubota V1505
Engine Power 29 HP
Cooling Water cooled diesel
Power Options and Accessories
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine, providing a dependable power source for field operations.
Optional configurations include:
Water booster pump
Skid-mounted configuration
Forklift tubing
These options provide additional flexibility for contractors who need to adapt the Shotcrete Machine to different jobsite conditions.
Applications of the Dry Process Shotcrete Machine
The Dry Process Shotcrete Machine can support a wide range of concrete spraying and placement applications. Depending on project requirements, the Multi-Rig can be considered for:
Concrete repair
Shotcrete construction
Tunnel construction
Mining projects
Underground construction
Slope stabilization
Structural rehabilitation
Infrastructure projects
Gunite applications
General concrete spraying
Its field-batching capability is particularly useful for projects where concrete sand and cement need to be mixed at the jobsite before being delivered to the gunite machine.
Benefits of the Multi-Rig System
The Multi-Rig combines mixing, material transfer, and gunite delivery into a single system. This integrated configuration can help contractors create a more efficient material-handling process.
The 1,500 lb. pan mixer provides substantial batching capacity, while the conveyor delivers the mixed material to the rotary gunite machine. Variable-speed operation allows the material output to be adjusted from 0 to 6 tons per hour.
The mixer tilt feature also makes cleanup easier after completing a job.
Choosing the Right Shotcrete Machine
When selecting a Shotcrete Machine, contractors should consider production capacity, material handling, mobility, power requirements, and the specific type of shotcrete application.
For dry mix applications requiring field batching, the Blastcrete Multi-Rig combines these functions into one trailer-mounted system. Its pan mixer, conveyor, and rotary gunite machine are designed to work together as an integrated Dry Process Shotcrete Machine.
Get More Information About the Blastcrete Multi-Rig
The Blastcrete Multi-Rig is designed for contractors who need a mobile solution for field batching and dry process shotcrete applications.
