Modern construction and concrete applications require reliable Gunite Equipment and efficient Concrete Batching Equipment to handle material preparation and delivery at the jobsite. The Blastcrete Multi-Rig combines field batching, material mixing, conveying, and rotary gunite operation in one integrated system designed for dry process shotcrete applications.
With a 1,500 lb. capacity pan mixer, variable-speed conveyor, and rotary gunite machine, the Multi-Rig provides a mobile solution for contractors working on demanding construction and industrial projects.
What Is the Blastcrete Multi-Rig?
The Multi-Rig is designed for field batching concrete sand and cement for dry process shotcrete applications. Instead of using separate systems for mixing and feeding material, the Multi-Rig integrates these functions into a single trailer-mounted unit.
The equipment features a 1,500 lb. capacity hydrostatic pan mixer that can be easily loaded using a skid steer. The material is blended in approximately 1.5 to 2 minutes before being discharged through the bottom slide door.
The mixed material then moves onto a rubber belt conveyor, which feeds the integrated rotary gunite machine. The gunite machine operates at variable speeds from 0 to 6 tons per hour.
Concrete Batching Equipment for Field Applications
Effective Concrete Batching Equipment is important when contractors need to prepare concrete materials directly at the project site.
The Multi-Rig's 1,500 lb. pan mixer provides field batching capability for concrete sand and cement. Its skid-steer loading configuration helps simplify material handling, while the relatively short mixing cycle supports an efficient batching process.
After the material is mixed, the bottom slide door allows it to discharge onto the conveyor for transfer to the gunite machine.
This integrated design can help create a continuous workflow from material batching to gunite application.
Professional Gunite Equipment
The rotary gunite component is an important part of the Multi-Rig system. With variable-speed operation from 0 to 6 tons per hour, the machine allows operators to adjust material output according to application requirements.
The conveyor feeds the rotary gunite machine directly, reducing the need for manual material transfer between the mixer and gunite equipment.
For contractors looking for integrated Gunite Equipment, the Multi-Rig combines material preparation and gunite delivery in a single mobile system.
Key Features of the Multi-Rig
The Blastcrete Multi-Rig includes several features designed for professional field operations.
1,500 lb. Hydrostatic Pan Mixer
The high-capacity pan mixer provides the batching and mixing function of the system. It is designed to be loaded with a skid steer and can blend materials in approximately 1.5 to 2 minutes.
Variable-Speed Rubber Belt Conveyor
Once the material is mixed, it is discharged onto the rubber belt conveyor. The conveyor transfers the material directly to the rotary gunite machine.
Variable-Speed Rotary Gunite Machine
The integrated gunite machine provides an output range of 0–6 tons per hour. Variable-speed operation allows the operator to adjust material delivery based on project requirements.
Mixer Tilt for Easy Cleanup
The mixer includes a tilt function designed to make cleanup easier after operation.
Multi-Rig Specifications
Specification Details
Output 0–6 tons per hour
Mixer Capacity 1,500 lbs.
Mounting Trailer mounted
Axles Dual electric braking axles
Lights Included
Dimensions 249" × 76" × 72"
Weight 7,000 lbs.
Engine Kubota V1505
Power 29 HP
Cooling Water cooled diesel
Kubota Diesel Power
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine.
The diesel power configuration provides the energy required to operate the integrated equipment system in field environments. This makes the Multi-Rig suitable for contractors who need mobile Gunite Equipment and Concrete Batching Equipment for professional applications.
Available Options
The Multi-Rig can be supplied with additional options depending on project requirements.
Available options include:
Water booster pump
Skid-mounted configuration
Forklift tubing
These options can provide additional flexibility for equipment handling, transportation, and jobsite setup.
Applications for Gunite and Concrete Batching Equipment
The combination of batching and gunite equipment makes the Multi-Rig suitable for a variety of applications, including:
Concrete repair
Tunnel construction
Mining
Underground construction
Slope stabilization
Structural rehabilitation
Infrastructure projects
Shotcrete spraying
Gunite applications
Concrete restoration
The field-batching capability can be particularly useful on projects where concrete sand and cement need to be prepared directly at the worksite.
Benefits of an Integrated Multi-Rig System
Using integrated Gunite Equipment and Concrete Batching Equipment can simplify material preparation and delivery.
The Multi-Rig performs several important functions in sequence:
Concrete sand and cement are loaded into the pan mixer.
The 1,500 lb. mixer blends the materials.
Mixed material is discharged through the bottom slide door.
The rubber belt conveyor transfers the material.
The rotary gunite machine delivers the material at a variable rate of up to 6 tons per hour.
This integrated process can help contractors maintain an organized workflow during dry process shotcrete operations.
Why Choose the Blastcrete Multi-Rig?
The Blastcrete Multi-Rig combines a field batching system with material conveying and rotary gunite equipment. Its trailer-mounted configuration provides mobility, while the pan mixer offers 1,500 lb. capacity for field batching.
For contractors searching for Gunite Equipment, Concrete Batching Equipment, mobile shotcrete systems, or dry process shotcrete machinery, the Multi-Rig provides an integrated configuration for professional field applications.
Request Information About the Multi-Rig
If you are looking for Gunite Equipment and Concrete Batching Equipment for construction, mining, tunneling, concrete repair, or infrastructure projects, the Blastcrete Multi-Rig can be evaluated according to your application requirements.
Visit the Quote Now page to request pricing and product information, or download the Multi-Rig brochure for additional technical details.
