Choosing the right Shotcrete Equipment Supplier is important for contractors who need reliable, efficient, and mobile equipment for dry-process shotcrete applications. The Blastcrete Multi-Rig combines field batching, mixing, material conveying, and rotary gunite application in one integrated system, making it a practical choice for demanding construction projects.
For contractors searching for a Mobile Shotcrete Machine, the Multi-Rig offers a trailer-mounted design with a high-capacity mixer, variable-speed conveyor, and rotary gunite machine.
Multi-Rig for Mobile Shotcrete Applications
The Blastcrete Multi-Rig is designed to field-batch concrete, sand, and cement for dry-process shotcrete applications. Its 1,500 lb. capacity hydrostatic pan mixer can be loaded easily with a skid steer.
The materials are blended in approximately 1.5 to 2 minutes before being discharged through the bottom slide door onto the rubber belt conveyor. The conveyor then feeds the rotary gunite machine, which provides variable output from 0 to 6 tons per hour.
The system is powered by a reliable 29 HP Kubota V1505 water-cooled diesel engine, providing a dependable power source for field operations.
Key Features
The Multi-Rig incorporates several components designed to streamline shotcrete production and application:
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable gunite output from 0–6 tons per hour
Mixer tilt function for easier cleanup
Trailer-mounted configuration for mobility
Mobile Shotcrete Machine Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted
Axles Dual electric braking axles with lights
Dimensions 249" × 76" × 72"
Weight 7,000 lbs.
Mixer Capacity 1,500 lbs.
Power Kubota V1505, 29 HP water-cooled diesel
Power Options
The Multi-Rig is equipped with a Kubota V1505 29 HP water-cooled diesel power option. This diesel-powered configuration is designed for field use where dependable equipment operation is essential.
Available Options
Depending on the project requirements, additional equipment options are available:
Water booster pump
Skid-mounted configuration with forklift tubing
These options provide additional flexibility when configuring the Multi-Rig for different jobsite conditions and material-handling needs.
Benefits of Choosing a Shotcrete Equipment Supplier
A dependable Shotcrete Equipment Supplier can help contractors identify equipment that matches their production requirements, jobsite conditions, and material-handling needs. An integrated system such as the Multi-Rig can simplify the workflow by combining batching, mixing, conveying, and gunite application into a single mobile unit.
The trailer-mounted design also allows the equipment to be transported between jobsites, making it a useful solution for contractors handling multiple shotcrete projects.
Why Choose the Multi-Rig Mobile Shotcrete Machine?
The Multi-Rig is designed for contractors who require a combination of mobility and production capability. Its 1,500 lb. mixer provides substantial material capacity, while the variable-speed conveyor and rotary gunite machine allow operators to manage material flow according to application requirements.
With production of up to 6 tons per hour, the system can support a range of dry-process shotcrete applications while maintaining a compact, integrated equipment configuration.
Get More Information
If you are looking for a Shotcrete Equipment Supplier or evaluating a Mobile Shotcrete Machine, the Blastcrete Multi-Rig provides an integrated solution for field batching and dry-process shotcrete applications.
