Shotcrete plays an important role in construction and ground-support applications where efficient concrete placement and reliable material handling are essential. The Blastcrete Multi-Rig is designed for field batching concrete, sand, and cement for dry-process shotcrete applications.
For contractors and operators searching for Tunnel Shotcrete Equipment or Mining Shotcrete Equipment, the Multi-Rig combines a high-capacity pan mixer, rubber belt conveyor, and rotary gunite machine in one mobile system.
Multi-Rig for Tunnel and Mining Applications
The Blastcrete Multi-Rig is designed to simplify field batching and material delivery for dry-process shotcrete operations. Its 1,500 lb. capacity hydrostatic pan mixer can be loaded easily with a skid steer.
Concrete, sand, and cement are blended in approximately 1.5 to 2 minutes. After mixing, the material is discharged through the bottom slide door onto the rubber belt conveyor. The conveyor then feeds the rotary gunite machine for controlled material delivery.
The rotary gunite machine provides variable production from 0 to 6 tons per hour, allowing operators to adjust output according to project requirements.
Key Features of the Multi-Rig
The Multi-Rig includes several features designed to support efficient field shotcrete production:
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable output from 0–6 tons per hour
Mixer tilt for easier cleanup
Trailer-mounted configuration
Reliable diesel power
Tunnel Shotcrete Equipment Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted
Axles Dual electric braking axles with lights
Dimensions 249" × 76" × 72"
Weight 7,000 lbs.
Mixer Capacity 1,500 lbs.
Power Kubota V1505, 29 HP water-cooled diesel
Efficient Mixing for Shotcrete Operations
Efficient batching and material preparation are important when using shotcrete equipment in demanding construction environments. The Multi-Rig's 1,500 lb. pan mixer provides the capacity needed to batch concrete, sand, and cement at the jobsite.
The mixer can be loaded with a skid steer, while the approximately 1.5 to 2 minute blending cycle helps prepare material for continuous transfer to the gunite machine.
Material Conveying and Gunite Application
After the mixing cycle, material is discharged through the bottom slide door onto the variable-speed rubber belt conveyor. The conveyor feeds the 020 rotary gunite machine, creating a streamlined path from batching to gunite application.
The rotary gunite machine can operate from 0 to 6 tons per hour, providing adjustable production for different project requirements.
Mining Shotcrete Equipment
In mining environments, equipment selection should account for the practical demands of material preparation, transportation, and application. The Multi-Rig's integrated design brings the mixer, conveyor, and rotary gunite machine together in a single equipment configuration.
Contractors evaluating Mining Shotcrete Equipment can consider the Multi-Rig when a mobile field-batching system is appropriate for their dry-process shotcrete requirements.
Actual suitability for a particular underground or mining project depends on site conditions, access, ventilation, safety requirements, and applicable regulations.
Power and Mobility
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine. Its trailer-mounted configuration includes dual electric braking axles and lights.
The mobile design allows contractors to transport the equipment between project locations, providing flexibility for operations where equipment needs to be relocated.
Additional Options
The Multi-Rig can be configured with additional equipment options, including:
Water booster pump
Skid-mounted configuration with forklift tubing
These options allow contractors to select a configuration based on project requirements and material-handling conditions.
Benefits of Multi-Rig Tunnel Shotcrete Equipment
The Multi-Rig combines several functions into one system, helping simplify the logistics of dry-process shotcrete production.
High-Capacity Mixer
The 1,500 lb. hydrostatic pan mixer provides substantial material capacity and can be loaded using a skid steer.
Adjustable Production
The rotary gunite machine provides output from 0 to 6 tons per hour, allowing operators to regulate material flow.
Mobile Configuration
The trailer-mounted design makes it possible to move the equipment between jobsites.
Easy Cleanup
The mixer tilt feature is designed to make post-operation cleanup more convenient.
Integrated Material Handling
The mixer, conveyor, and rotary gunite machine work together as an integrated system for dry-process shotcrete operations.
Request More Information
If you are researching Tunnel Shotcrete Equipment or Mining Shotcrete Equipment, the Blastcrete Multi-Rig offers a mobile solution for field batching and dry-process gunite operations.
