Reliable power is an important consideration when selecting equipment for field shotcrete operations. The Blastcrete Multi-Rig is designed for field batching concrete, sand, and cement for dry-process shotcrete applications and combines mixing, conveying, and rotary gunite functions in one mobile system.
For contractors searching for a diesel powered shotcrete machine or a Kubota diesel shotcrete machine, the Multi-Rig offers a diesel-powered configuration with a 1,500 lb. capacity pan mixer and variable-output rotary gunite machine.
Blastcrete Multi-Rig Diesel Powered Shotcrete Machine
The Multi-Rig is equipped with a 1,500 lb. capacity hydrostatic pan mixer that can be loaded easily with a skid steer. Concrete, sand, and cement are blended in approximately 1.5 to 2 minutes.
After mixing, the material is discharged through the bottom slide door onto a variable-speed rubber belt conveyor. The conveyor then feeds the 020 rotary gunite machine.
The rotary gunite machine provides variable production from 0 to 6 tons per hour, allowing operators to adjust material output according to the requirements of the application.
Kubota Diesel Power
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine. This provides a dedicated diesel power source for field operation.
The Kubota-powered configuration is designed for contractors who need a mobile shotcrete system with integrated batching and gunite equipment. As with any diesel-powered equipment, operation should follow the manufacturer's requirements and applicable jobsite safety procedures.
1,500 lb. Hydrostatic Pan Mixer
The Multi-Rig's pan mixer provides 1,500 lb. of capacity for field batching.
The mixer can be loaded using a skid steer, and the material is blended in approximately 1.5 to 2 minutes. Once the mixing cycle is complete, the bottom slide door allows the material to discharge directly onto the conveyor.
A mixer tilt function is also included to help simplify cleanup.
Variable-Speed Conveyor
The variable-speed rubber belt conveyor provides controlled material transfer from the pan mixer to the rotary gunite machine.
This integrated design helps streamline the material-handling process by connecting the batching and gunite stages within the same equipment system.
0–6 Tons per Hour Rotary Gunite Production
The Multi-Rig includes an 020 rotary gunite machine with variable output from 0 to 6 tons per hour.
The adjustable production capability allows contractors to regulate material delivery according to project specifications, material characteristics, and application requirements.
Multi-Rig Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted
Axles Dual electric braking axles with lights
Dimensions 249" × 76" × 72"
Weight 7,000 lbs.
Mixer Capacity 1,500 lbs.
Gunite Machine 020 rotary gunite machine
Power Kubota V1505, 29 HP water-cooled diesel
Trailer-Mounted Diesel Shotcrete Equipment
The Multi-Rig is configured as trailer-mounted shotcrete equipment, making it suitable for contractors who need to transport the system between appropriate project locations.
The trailer is equipped with dual electric braking axles and lights. The complete system has listed dimensions of 249" × 76" × 72" and a listed weight of 7,000 lbs.
Transportation, setup, and operation should be carried out according to applicable regulations and manufacturer instructions.
Key Features
The Multi-Rig diesel shotcrete system includes:
1,500 lb. hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable output from 0–6 tons per hour
Kubota V1505 29 HP water-cooled diesel
Mixer tilt for easy cleanup
Trailer-mounted configuration
Dual electric braking axles and lights
Available Options
The Multi-Rig can be configured with additional options for specific project requirements:
Water Booster Pump
A water booster pump is available as an optional configuration where required by the application.
Skid Mount with Forklift Tubing
A skid-mounted configuration with forklift tubing is also available, providing an alternative equipment-handling arrangement.
Benefits of a Kubota Diesel Shotcrete Machine
A diesel-powered integrated shotcrete system can provide contractors with a dedicated power source for field batching and gunite operations.
The Multi-Rig combines this diesel power with a high-capacity pan mixer and variable-output rotary gunite machine. This configuration can simplify equipment logistics for suitable dry-process shotcrete projects.
Diesel Powered Shotcrete Machine: Multi-Rig Kubota Diesel Shotcrete Machine
