Efficient material preparation is essential for consistent dry-process shotcrete applications. The Blastcrete Multi-Rig combines a high-capacity shotcrete mixer, conveyor, and rotary gunite machine into one mobile system designed for field batching shotcrete equipment applications.
With its integrated mixing and material transfer system, the Multi-Rig allows contractors to batch concrete, sand, and cement at the job site before delivering the prepared material to the gunite machine.
Complete Field Batching Shotcrete Equipment
The Multi-Rig is designed specifically for field batching concrete, sand, and cement for dry-process shotcrete applications. Its 1,500 lb. capacity hydrostatic pan mixer can be easily loaded with a skid steer, helping simplify material handling on the job site.
The mixer blends the materials in approximately 1.5 to 2 minutes. Once mixing is complete, the bottom slide door releases the material onto the integrated rubber belt conveyor. The conveyor transfers the mixed material directly to the rotary gunite machine for application.
This integrated process provides a practical solution for projects that require mobile batching and shotcrete material delivery.
Shotcrete Mixer and Gunite Machine in One System
The Multi-Rig combines two important stages of dry-process shotcrete production: material mixing and gunite delivery.
The pan mixer prepares the concrete, sand, and cement mixture, while the variable-speed conveyor provides continuous material transfer to the 020 rotary gunite machine. The gunite machine offers variable production from 0 to 6 tons per hour, allowing operators to adjust output according to project requirements.
This combination makes the Multi-Rig a versatile choice for contractors seeking a shotcrete mixer and gunite machine for field operations.
Key Features
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Gunite output from 0–6 tons per hour
Mixer tilt function for easy cleanup
Skid-steer loading capability
Trailer-mounted configuration
Reliable diesel-powered operation
Multi-Rig Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted with dual electric braking axles and lights
Dimensions 249" x 76" x 72"
Weight 7,000 lbs.
Pan Mixer Capacity 1,500 lbs.
Mixing Time Approximately 1.5–2 minutes
Power Kubota V1505, 29 HP water-cooled diesel
Reliable Diesel Power
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine. This power option provides a dependable source of power for field batching and shotcrete operations.
The mobile configuration allows the equipment to be transported to different job sites while providing the mixing and gunite capabilities required for dry-process applications.
Options for Different Job Requirements
The Multi-Rig can be equipped with additional options to accommodate specific project needs, including:
Water booster pump
Skid-mounted configuration with forklift tubing
These options provide additional flexibility when configuring the equipment for different site conditions and material-handling requirements.
Advantages of Mobile Shotcrete Equipment
Field batching can be particularly useful when contractors need to prepare shotcrete materials directly at the project location. By combining the mixer, conveyor, and gunite machine, the Multi-Rig helps streamline the movement of material from batching through application.
The fast mixing cycle, variable conveyor operation, and adjustable gunite output provide operators with control over the material preparation and delivery process.
