Efficient batching and material delivery are important for contractors working on dry-process shotcrete and gunite projects. The Blastcrete Multi-Rig is designed for field batching concrete, sand, and cement and combines a high-capacity pan mixer, rubber belt conveyor, and rotary gunite machine in one mobile system.
For contractors searching for Shotcrete Equipment Qatar or a Shotcrete Machine Oman, the Multi-Rig offers an integrated solution for preparing and delivering shotcrete materials at the job site.
Shotcrete Equipment Qatar for Field Batching
The Multi-Rig is equipped with a 1,500 lb. capacity hydrostatic pan mixer that can be easily loaded using a skid steer. Concrete, sand, and cement are blended in approximately 1.5 to 2 minutes.
After the mixing cycle, the material is discharged through the bottom slide door onto the rubber belt conveyor. The conveyor transfers the prepared material directly to the rotary gunite machine, creating an efficient flow from batching to application.
Shotcrete Machine Oman for Dry-Process Applications
For contractors seeking a Shotcrete Machine Oman solution, the Multi-Rig combines material mixing and gunite delivery in a mobile configuration.
The integrated 020 rotary gunite machine features variable output from 0 to 6 tons per hour. Operators can adjust production according to project requirements and application conditions.
The system's integrated design helps simplify material handling by connecting the pan mixer, conveyor, and gunite machine into one coordinated operation.
Key Multi-Rig Features
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable output from 0–6 tons per hour
Mixer tilt function for easy cleanup
Trailer-mounted configuration
Dual electric braking axles and lights
Skid-steer loading capability
Multi-Rig Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted with dual electric braking axles and lights
Dimensions 249" x 76" x 72"
Weight 7,000 lbs.
Mixer Capacity 1,500 lbs.
Mixing Time Approximately 1.5–2 minutes
Reliable Power for Mobile Shotcrete Operations
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine. The diesel power option is designed to provide dependable operation for field batching and rotary gunite applications.
Its trailer-mounted configuration supports transportation between work locations, making the system suitable for mobile shotcrete projects.
Available Equipment Options
The Multi-Rig can be configured with additional options based on specific project and site requirements.
Available options include:
Water booster pump
Skid-mounted configuration with forklift tubing
These options offer greater flexibility for equipment positioning, transportation, and material-handling requirements.
Efficient Material Mixing and Conveying
A key advantage of the Multi-Rig is the integration of batching and material transfer. Concrete, sand, and cement can be loaded into the pan mixer using a skid steer and blended in a short cycle.
Once mixed, the material is discharged onto the conveyor and transferred directly to the rotary gunite machine. The variable-speed conveyor and gunite machine provide operators with control over material flow and production.
Mobile Shotcrete Solutions for Qatar and Oman
Construction projects in Qatar and Oman may require mobile equipment capable of supporting dry-process shotcrete applications at different job sites. The Multi-Rig's trailer-mounted design provides a convenient way to transport batching and gunite equipment as project requirements change.
Its combination of a high-capacity mixer, conveyor, and rotary gunite machine provides an integrated approach to field batching and shotcrete material delivery.
