Modern shotcrete projects require reliable equipment for batching, mixing, conveying, and material application. The Blastcrete Multi-Rig is designed for field batching concrete, sand, and cement for dry-process shotcrete applications. By combining a high-capacity pan mixer, rubber belt conveyor, and rotary gunite machine, the Multi-Rig provides an integrated mobile solution.
For contractors searching for Shotcrete Equipment Middle East or a Shotcrete Machine USA, the Multi-Rig offers a practical system for field batching and dry-process shotcrete operations.
Shotcrete Equipment Middle East for Field Applications
The Multi-Rig is equipped with a 1,500 lb. capacity hydrostatic pan mixer that can be easily loaded using a skid steer. Concrete, sand, and cement are blended in approximately 1.5 to 2 minutes.
After mixing, the material is discharged through the bottom slide door onto the integrated rubber belt conveyor. The conveyor then transfers the prepared material directly to the rotary gunite machine.
This integrated process helps connect material batching and shotcrete application while reducing the need for separate material-transfer equipment.
Shotcrete Machine USA for Dry-Process Shotcrete
The Multi-Rig incorporates an 020 rotary gunite machine with variable output from 0 to 6 tons per hour. Operators can adjust the production rate according to project requirements.
The system is designed to support dry-process shotcrete applications where concrete, sand, and cement are prepared in the field and then delivered continuously to the gunite machine.
For contractors evaluating a Shotcrete Machine USA solution, the Multi-Rig combines mixing, conveying, and rotary gunite functions in a single mobile platform.
Key Features of the Multi-Rig
1,500 lb. capacity hydrostatic pan mixer
Variable-speed rubber belt conveyor
020 rotary gunite machine
Variable output from 0–6 tons per hour
Mixer tilt function for easy cleanup
Trailer-mounted configuration
Dual electric braking axles and lights
Skid-steer loading capability
Multi-Rig Specifications
Specification Details
Output 0–6 tons per hour
Mounting Trailer mounted with dual electric braking axles and lights
Dimensions 249" x 76" x 72"
Weight 7,000 lbs.
Mixer Capacity 1,500 lbs.
Mixing Time Approximately 1.5–2 minutes
Reliable Diesel Power
The Multi-Rig is powered by a Kubota V1505 29 HP water-cooled diesel engine. This power option is designed to provide dependable operation for field batching and rotary gunite applications.
The trailer-mounted configuration also supports transportation between job sites, making the Multi-Rig suitable for mobile shotcrete operations in different working environments.
Available Options
The Multi-Rig can be configured with additional options to meet different project requirements.
Available options include:
Water booster pump
Skid-mounted configuration with forklift tubing
These options provide flexibility for equipment positioning, transportation, and site-specific material-handling requirements.
Efficient Batching and Material Delivery
The Multi-Rig brings the key stages of dry-process shotcrete production together in one system. A skid steer can load the pan mixer, where the concrete, sand, and cement are blended before being discharged onto the conveyor.
The conveyor feeds the rotary gunite machine, while the variable-speed operation allows material output to be adjusted as needed.
This integrated approach can simplify field operations and provide a coordinated material flow from batching through gunite application.
Mobile Shotcrete Solutions for the Middle East and USA
Contractors working across different regions may require mobile shotcrete equipment that can support field batching and dry-process applications. The Multi-Rig's trailer-mounted configuration, diesel power, and integrated material-handling components provide a flexible equipment platform.
Shotcrete Equipment Middle East: Multi-Rig Shotcrete Machine USA
