Furnace lining projects in steel production require reliable equipment for preparing and placing refractory materials efficiently. The Blastcrete MX-20CM Mixer/Pump combines a high-shear continuous mixer with a high-pressure swing tube piston pump, providing an integrated system for demanding refractory placement applications.
For contractors and industrial operators searching for a refractory mixer for furnace lining or refractory equipment for the steel industry, the MX-20CM offers a stated mixing and pumping capacity of up to 25 tons per hour.
MX-20CM for Furnace Lining Applications
The MX-20CM is designed around a two-stage mixing process. Its primary high-shear continuous mixer hydrates the material, while a medium-shear secondary mixer is installed in the receiving hopper of the 4-inch swing tube pump.
This configuration allows material to move from continuous mixing into pumping while supporting both smaller refractory installations and high-volume applications. The supplied specifications indicate an operating range of approximately 2–3 tons per hour for smaller installations and up to 25 tons per hour for high-volume work.
For furnace lining projects, this integrated arrangement can help reduce the need for separate mixing and pumping equipment on the job site.
Refractory Equipment for the Steel Industry
Steel-industry refractory applications can involve demanding installation environments and substantial material volumes. The MX-20CM is equipped with a 4-inch x 36-inch ultra-high-pressure swing tube piston pump with a specified 2,200 PSI piston face pressure.
The pump is intended for rugged refractory pump-cast and shotcrete applications. Its oversized differential cylinders are designed to allow lower hydraulic operating pressure while maintaining the pump's high-pressure capability.
Two-Stage Mixing System
One of the main advantages of the MX-20CM is its two-stage mixing arrangement.
Primary High-Shear Mixer
The primary continuous mixer provides high-shear mixing and material hydration. It has a stated output of up to 25 tons per hour, supporting continuous material preparation for larger installation projects.
Secondary Mixer
A medium-shear secondary mixer is mounted inside the receiving hopper. This helps maintain material preparation immediately before the refractory material enters the pumping system.
The supplied product information also states that dust generated while charging the continuous mixer is largely eliminated and that cleanup can be faster with reduced waste.
Easy Access for Cleaning and Maintenance
The MX-20CM incorporates a swing-out receiving hopper that provides access to the swing tube section. This design is intended to simplify cleaning and maintenance.
Forklift tubing is mounted to the lower hopper to assist with flat-pack removal, while a four-point crane pickup allows the machine to be lifted without a spreader bar.
These features can be useful when equipment is moved between furnace lining areas or other industrial refractory installation locations.
MX-20CM Features
High-shear continuous mixer
Mixer output up to 25 tons/hour
Pump output up to 25 tons/hour
4" x 36" swing tube piston pump
2,200 PSI piston face pressure
3,000-lb dry hopper capacity
1,500-lb receiving hopper capacity
Hydraulic agitator in receiving hopper
0–20 gallon flow meter
Solid-state electronic controls
Swing-out receiving hopper
Forklift tubing for flat-pack removal
Four-point crane pickup
CE certification
Dual 6,000-lb-capacity axles
Electric trailer brakes and lights
MX-20CM Specifications
Specification MX-20CM
Pump 4" x 36" Ultra High Pressure Swing Tube Pump
Pump Output 0–25 tons/hour
Piston Face Pressure 2,200 PSI
Mixer High-Shear Continuous Mixer
Mixer Output 0–25 tons/hour
Dry Hopper 3,000 lb capacity
Receiving Hopper 1,500 lb capacity
Receiving Hopper Hydraulic agitator
Crane Pickup Four-point pickup
Controls Solid-state electronic
Trailer Dual 6,000-lb-capacity axles
Dimensions 220" x 89" x 108"
Weight 7,500 lb
Power Options
The MX-20CM can be configured with different power systems:
99 HP John Deere water-cooled diesel
102 HP Deutz water-cooled diesel
Dual electric motors
The supplied product information states that the machine requires approximately 100 HP and that its two-stage mixer and oversized differential design can reduce fuel consumption compared with competitive machines.
Options for Industrial Refractory Work
Additional options include:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Spare tire
Pendant remote
Skid mounting with forklift tubing
These options provide additional flexibility for transportation, maintenance, and job-site operation.
Benefits for Furnace Lining Projects
Using a combined mixer and pump can simplify refractory installation logistics. Instead of coordinating separate mixing and pumping systems, the MX-20CM integrates both functions into one machine.
For furnace lining work, its key advantages include:
High production capacity: The mixer and pump are both specified for outputs up to 25 tons per hour.
Continuous material preparation: The two-stage mixing arrangement is designed for continuous material hydration and delivery.
High-pressure pumping: The 4-inch swing tube piston pump provides a specified 2,200 PSI piston face pressure.
Maintenance access: The swing-out hopper makes the pumping section easier to access for cleaning and service.
Mobile design: The trailer configuration allows the machine to be transported between suitable work areas.
MX-20CM for Steel-Industry Refractory Installation
When evaluating refractory equipment for the steel industry, production capacity, material handling, maintenance access, and job-site mobility are important considerations. The MX-20CM brings these functions together in a single mixer/pump platform.
Its stated capacity of up to 25 tons per hour makes it suitable for consideration on high-volume refractory projects, while its ability to operate at lower production rates provides flexibility for smaller installations.
