Efficient material preparation and dependable pumping are essential for demanding refractory installation projects. The Blastcrete MX-20CM Mixer/Pump combines a high-shear continuous mixer and a high-pressure swing-tube piston pump into one mobile system, providing a practical solution for both smaller refractory jobs and high-volume installations.
The MX-20CM is designed specifically around continuous refractory placement. Its primary mixer uses a high-shear mixing process to hydrate material before transferring it to a secondary mixer positioned inside the receiving hopper.
The system is rated for approximately 0–25 tons per hour, allowing it to accommodate projects ranging from smaller installations of around 2–3 tons per hour to demanding high-volume work.
For companies evaluating a refractory mixer manufacturer, an integrated mixer-and-pump configuration can provide advantages in material handling, production continuity, and jobsite mobility.
High-Shear Continuous Mixing
At the center of the MX-20CM is a compact two-stage mixing system.
The primary high-shear continuous mixer is responsible for hydrating the refractory material. A secondary medium-shear mixer in the receiving hopper then helps maintain material movement before pumping.
Key advantages of the design include:
Continuous material mixing
Rated mixing capacity of up to 25 tons per hour
Reduced dust during charging
Faster mixer cleanup
Low material waste
Continuous transfer to the pumping system
This arrangement makes the MX-20CM suitable for contractors requiring consistent material processing during extended refractory installation operations.
High-Pressure Swing-Tube Pump
The MX-20CM incorporates a 4-inch x 36-inch ultra-high-pressure swing-tube piston pump.
The pump provides a specified 2,200 PSI piston face pressure and is rated for output of up to 25 tons per hour. It is designed for demanding refractory pump-cast and shotcrete applications.
Oversized differential cylinders allow the pump to maintain high discharge pressure while operating with comparatively lower hydraulic pressure.
Designed for Easier Maintenance
Maintenance accessibility is an important consideration when selecting refractory installation machinery.
The MX-20CM features a swing-out receiving hopper that provides access to the swing-tube section for cleaning and servicing. This design can help reduce the time required for routine maintenance.
Additional features include:
Forklift tubing mounted to the lower hopper
Four-point crane pickup
No spreader bar required for crane pickup
Solid-state electronic controls
0–20 gallon flow meter
Electric-braked trailer
MX-20CM Specifications
Specification MX-20CM
Pump 4" x 36" Ultra High Pressure Swing Tube Pump
Pump Output 0–25 tons/hour
Piston Face Pressure 2,200 PSI
Mixer High-Shear Continuous Mixer
Mixer Output 0–25 tons/hour
Dry Hopper 3,000 lb. capacity
Receiving Hopper 1,500 lb. capacity with hydraulic agitator
Crane Pickup Four-point pickup
Flow Meter 0–20 gallons
Dimensions 220" x 89" x 108"
Weight 7,500 lb.
Trailer Dual 6,000 lb. capacity axles
Certification CE
Diesel and Electric Power Configurations
The MX-20CM can be supplied with different power configurations depending on operating requirements.
Available options include:
99 HP John Deere water-cooled diesel
102 HP Deutz water-cooled diesel
Dual electric motors
This range of power options gives contractors flexibility when selecting equipment for mobile or electrically powered work environments.
Optional Equipment
Additional options can be specified for the MX-20CM, including:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Mounted spare tire
Pendant remote
Skid mounting with forklift tubing
These options can help adapt the machine to different jobsite and maintenance requirements.
Applications for Refractory Installation
The MX-20CM is designed for refractory material placement and can support applications such as:
Furnace refractory installation
Industrial lining work
Refractory pump casting
High-temperature equipment maintenance
Shotcrete applications
High-volume refractory placement
Industrial repair projects
Specific material compatibility and production rates should be evaluated according to the refractory formulation, pumping distance, hose arrangement, and jobsite conditions.
Why Choose Integrated Refractory Installation Machinery?
A combined mixer/pump can reduce the need to coordinate separate mixing and pumping equipment. With the MX-20CM, material mixing, hydration, secondary mixing, and pumping are incorporated into one system.
For contractors comparing a refractory mixer manufacturer, important factors include:
Mixing capacity — The MX-20CM is rated up to 25 tons per hour.
Pump capability — Its 4-inch x 36-inch swing-tube pump provides 2,200 PSI piston face pressure.
Maintenance access — The swing-out receiving hopper facilitates access to the pumping section.
Mobility — The trailer configuration supports movement between jobsites.
Power flexibility — Diesel and dual-electric configurations are available.
Handling — Forklift tubing and four-point crane pickup simplify equipment movement.
The Blastcrete MX-20CM Mixer/Pump combines continuous high-shear mixing with high-pressure pumping in a single piece of refractory installation machinery. With a rated capacity of up to 25 tons per hour, 2,200 PSI piston face pressure, multiple power options, and maintenance-oriented features, it is designed for demanding refractory placement and shotcrete applications.
Businesses researching a refractory mixer manufacturer can consider the MX-20CM when they need an integrated system capable of supporting both smaller refractory installations and high-volume industrial projects.
