When planning a refractory installation project, obtaining a detailed refractory equipment quotation helps contractors evaluate equipment capacity, pumping performance, power requirements, and available options before making a purchasing decision. The Blastcrete MX-20CM Mixer/Pump combines continuous high-shear mixing with high-pressure pumping in a single mobile machine designed for demanding refractory and shotcrete applications.
What to Consider in a Refractory Equipment Quotation
A useful refractory pump quotation should go beyond the basic machine price. Contractors should consider the pump's rated output, pressure capability, mixer capacity, power configuration, transportation requirements, and optional equipment.
The MX-20CM is designed for both smaller installations and high-volume refractory placement. Its supplied specifications list a rated pump and mixer capacity of 0–25 tons per hour.
Actual production can vary depending on material characteristics, mix design, conveying distance, hose configuration, and jobsite conditions.
Two-Stage Mixing for Consistent Material Processing
The MX-20CM uses a compact two-stage mixing system. The primary high-shear continuous mixer hydrates the material before it moves into a medium-shear secondary mixer located in the receiving hopper.
This integrated design is intended to provide:
Continuous material mixing
Hydration during primary mixing
Up to 25 tons/hour rated mixer output
Reduced dust during charging
Faster cleanup
Low material waste
Continuous feeding to the pump
For contractors requesting a refractory equipment quotation, the two-stage mixer is an important feature to evaluate when high-volume material processing is required.
High-Pressure Pumping Capability
The MX-20CM incorporates a 4-inch x 36-inch ultra-high-pressure swing-tube piston pump with a specified 2,200 PSI piston face pressure.
The pump is designed for demanding refractory pump-cast and shotcrete applications. Oversized differential cylinders help reduce the hydraulic pressure needed to operate the pumping system while maintaining high discharge pressure.
A refractory pump quotation should therefore be evaluated alongside the project's required pumping distance, material type, output rate, and operating conditions rather than on pump pressure alone.
Easy Access for Cleaning and Maintenance
Maintenance requirements can have a significant impact on equipment ownership costs. The MX-20CM features a swing-out receiving hopper that provides access to the swing-tube section for cleaning and maintenance.
Other service-oriented features include:
Forklift tubing mounted to the lower hopper
Four-point crane pickup
No spreader bar required for crane pickup
Solid-state electronic controls
0–20 gallon flow meter
These features are intended to simplify routine equipment handling and servicing.
MX-20CM Specifications
Specification MX-20CM
Pump 4" x 36" Ultra High Pressure Swing Tube Pump
Pump Output 0–25 tons/hour
Piston Face Pressure 2,200 PSI
Mixer High-Shear Continuous Mixer
Mixer Output 0–25 tons/hour
Dry Hopper 3,000 lb. capacity
Receiving Hopper 1,500 lb. capacity
Receiving Hopper Hydraulic agitator
Flow Meter 0–20 gallons
Dimensions 220" x 89" x 108"
Weight 7,500 lb.
Trailer Dual 6,000 lb. capacity axles
Certification CE
Power Options to Include in Your Quote
The MX-20CM is available with several power configurations:
99 HP John Deere water-cooled diesel
102 HP Deutz water-cooled diesel
Dual electric motors
When requesting a refractory equipment quotation, specifying the preferred power configuration can help ensure that the quotation reflects the intended operating environment.
Available Options
Depending on project requirements, the MX-20CM can be equipped with additional options such as:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Mounted spare tire
Pendant remote
Skid mounting with forklift tubing
Including required options in the initial quotation can make equipment comparisons easier and provide a clearer estimate of the complete project setup.
Trailer-Mounted Refractory Mixer/Pump
The MX-20CM has a listed towing weight of 7,500 pounds and uses a trailer with dual 6,000-pound-capacity axles, electric braking, and lights.
Its four-point crane pickup also provides a practical method for lifting the equipment when required. The manufacturer lists the machine as CE certified.
For mobile refractory contractors, these features can be important considerations when preparing a total equipment budget.
Applications
The MX-20CM is intended for refractory placement and related shotcrete applications, including projects involving:
Industrial refractory installation
Refractory pump casting
Furnace maintenance
High-temperature equipment repair
Industrial lining work
High-volume refractory placement
Shotcrete applications
Material compatibility and operating requirements should be confirmed for each specific project.
How to Request an MX-20CM Quote
When requesting a refractory pump quotation, provide the supplier with as much project information as possible. Useful details can include:
Required production rate
Refractory material and mix design
Required pumping distance
Intended application
Preferred diesel or electric power
Required accessories and options
Delivery location and transportation requirements
Providing these details allows the supplier to prepare a more relevant equipment proposal.
The Blastcrete MX-20CM Mixer/Pump combines a high-shear continuous mixer and a 4-inch swing-tube piston pump into one mobile refractory placement system. With a rated capacity of up to 25 tons per hour, 2,200 PSI piston face pressure, multiple power options, and maintenance-friendly features, it is designed for applications ranging from smaller refractory installations to high-volume projects.
If you are comparing a refractory equipment quotation or requesting a refractory pump quotation, the MX-20CM's pumping capacity, mixer performance, power configuration, options, and transportation requirements should all be considered when evaluating the complete equipment package.
