The D3522 Pump is a compact 2" hydraulic squeeze pump designed for contractors who need controlled material pumping across a range of construction and repair applications. This versatile machine can be used for concrete repair, epoxy, block fill, plaster, and stucco applications.
With variable output from 0 to 6 cubic yards per hour and pumping pressure up to 400 PSI, the D3522 provides a practical solution for projects that require a compact and flexible hydraulic squeeze pump.
What Is a 2" Hydraulic Squeeze Pump?
A 2" hydraulic squeeze pump is a pumping system designed to move compatible construction materials through a 2-inch discharge line using hydraulic power. The D3522 combines this pumping technology with a heavy-duty planetary gearbox for a compact and straightforward equipment package.
The variable-speed design allows operators to adjust output according to the requirements of the application. With output ranging from 0–6 cubic yards per hour, the D3522 can accommodate different production requirements.
D3522 Pump: Compact Hydraulic Squeeze Pump
The D3522 Pump is designed around a 2-inch hydraulic squeeze pumping system. Its compact configuration makes it suitable for contractors working on repair, rehabilitation, and specialty construction projects.
The pump features a 6 cubic foot receiving hopper, a 2-inch HD discharge, and a maximum pumping pressure of 400 PSI.
The D3522 can also be supplied in either a trailer-mounted or lower-profile skid-mounted configuration, providing flexibility for transportation and job-site use.
Key Features of the D3522 Pump
2" Hydraulic Squeeze Pump
The central component of the D3522 is its 2" hydraulic squeeze pump, driven by a heavy-duty planetary gearbox. This configuration is designed for reliable material pumping in demanding construction environments.
Variable Output
The D3522 provides an output range of 0–6 cubic yards per hour. Variable-speed operation allows the operator to control material delivery according to the job.
6 Cubic Foot Receiving Hopper
The machine includes a 6 cubic foot receiving hopper, providing material capacity before pumping begins.
Compact Design
The D3522 is designed as a compact pumping unit that can be configured for trailer mounting or a lower-profile skid mount.
Durable Pumping Tubes
The D3522 is designed with long-lasting pumping tubes intended to support extended equipment service and reduce maintenance requirements.
Applications for a Hydraulic Squeeze Pump
The versatility of the hydraulic squeeze pump makes the D3522 suitable for several applications.
Concrete Repair
The D3522 Pump can be used for suitable concrete repair applications where controlled pumping of repair materials is required.
Epoxy Applications
For compatible materials, the D3522 can support epoxy pumping applications used in specialized construction and repair work.
Block Fill
The pump can be used for block fill applications, helping contractors deliver compatible fill material efficiently.
Plaster and Stucco
The D3522 can also be used in various plaster and stucco applications, providing contractors with one machine for multiple types of specialty work.
D3522 Pump Specifications
Specification Details
Pump 2" D3522 Hydraulic Squeeze Pump
Pumping Pressure 400 PSI
Output 0–6 Cubic Yards Per Hour
Discharge 2" HD
Hopper 6 cu. ft.
Trailer Single 6,000 lb. capacity axle with electric braking and lights
Dimensions 166" × 88" × 54"
Weight 2,800 lbs.
D3522 Power Options
The D3522 Pump can be configured with different power sources depending on project requirements:
Kubota water-cooled diesel
24 HP Honda gasoline engine
10 HP electric motor
Having multiple power options gives contractors flexibility when selecting a D3522 configuration for different job-site environments.
Available D3522 Options
The D3522 can also be equipped with additional options, including:
Hydraulic receiving hopper agitator
Pendant or wireless remote
Spare tire mounted
Skid mounted with forklift tubing
Hydraulic pressure washer
Mounted air compressor
These options can help contractors customize their hydraulic squeeze pump setup according to transportation, operation, and job-site requirements.
Why Choose the D3522 Hydraulic Squeeze Pump?
The D3522 Pump combines a compact design with variable-speed operation, multiple power options, and flexible mounting configurations.
For contractors searching for a 2" hydraulic squeeze pump, the D3522 offers:
0–6 cubic yards per hour variable output
Up to 400 PSI pumping pressure
2-inch HD discharge
6 cubic foot receiving hopper
Trailer or skid mounting options
Diesel, gasoline, or electric power options
Applications for concrete repair, epoxy, block fill, plaster, and stucco
Its flexible configuration makes the D3522 a useful option for contractors who require a compact pumping machine for specialized construction and repair work.
