Choosing the right concrete pumping equipment is important for contractors working on concrete repair, block fill, epoxy, plaster, stucco, and other specialty construction applications. The D3522 Pump is a compact 2-inch hydraulic squeeze pump designed to provide controlled material pumping with variable output and flexible mounting configurations.
With an output range of 0–6 cubic yards per hour and pumping pressure of up to 400 PSI, the D3522 offers a compact solution for suitable pumping applications where mobility, versatility, and controlled material delivery are important.
What Is the D3522 Pump?
The D3522 is a compact 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox. It is designed for contractors who require versatile concrete pumping equipment for repair and specialty construction work.
The machine includes a 6 cubic foot receiving hopper and a 2-inch HD discharge. Its variable-speed operation allows operators to adjust the output according to project requirements.
The D3522 can be configured as a trailer-mounted machine or as a lower-profile skid-mounted unit, providing flexibility for different job-site conditions.
D3522 Concrete Pumping Equipment Features
The D3522 combines several features designed for practical operation and maintenance.
2-Inch Hydraulic Squeeze Pump
The D3522 uses a 2-inch hydraulic squeeze pumping system powered by a heavy-duty planetary gearbox. This configuration provides a compact pumping solution for compatible construction materials.
Variable Output
The machine offers output from 0 to 6 cubic yards per hour. Variable-speed operation allows contractors to control material delivery based on the needs of the application.
6 Cubic Foot Receiving Hopper
A 6 cubic foot receiving hopper provides material capacity for the pumping system and supports efficient job-site operation.
Trailer or Skid Mounting
The D3522 can be supplied in a trailer-mounted configuration or as a lower-profile skid-mounted unit. This provides contractors with options for transportation and positioning.
Durable Pumping Tubes
The pump is designed with long-lasting pumping tubes intended to support dependable operation and help control maintenance requirements.
Applications of the D3522 Pump
The versatility of the D3522 makes it useful for several construction and repair applications involving compatible materials.
Concrete Repair
The D3522 can be used as concrete pumping equipment for suitable concrete repair applications where controlled material placement is required.
Epoxy Applications
The machine can support appropriate epoxy pumping applications, making it useful for certain specialized construction and repair projects.
Block Fill
The D3522 can be used for compatible block fill applications where material needs to be delivered efficiently into masonry structures.
Plaster and Stucco
The pump is also suitable for various plaster and stucco applications, providing contractors with a versatile machine for specialty construction work.
D3522 Pump Specifications
Specification Details
Pump 2" D3522 Hydraulic Squeeze Pump
Pumping Pressure 400 PSI
Output 0–6 Cubic Yards Per Hour
Discharge 2" HD
Hopper 6 cu. ft.
Trailer Single 6,000 lb. capacity axle with electric braking and lights
Dimensions 166" × 88" × 54"
Weight 2,800 lbs.
Power Options for the D3522
The D3522 Pump is available with multiple power options:
Kubota water-cooled diesel
24 HP Honda gasoline engine
10 HP electric motor
The available power configurations allow contractors to select an appropriate setup for their operating environment and project requirements.
Optional Equipment
The D3522 can also be configured with additional options:
Hydraulic receiving hopper agitator
Pendant or wireless remote
Spare tire mount
Skid mount with forklift tubing
Hydraulic pressure washer
Mounted air compressor
These options provide additional flexibility when configuring the D3522 for different job-site requirements.
Benefits of D3522 Concrete Pumping Equipment
For contractors seeking compact concrete pumping equipment, the D3522 offers a combination of variable output, multiple power options, and flexible mounting configurations.
Key characteristics include:
Compact 2-inch hydraulic squeeze pump
0–6 cubic yards per hour variable output
Up to 400 PSI pumping pressure
6 cubic foot receiving hopper
Trailer or skid-mounted configurations
Diesel, gasoline, or electric power options
Applications for concrete repair, epoxy, block fill, plaster, and stucco
This combination makes the D3522 a flexible option for contractors working on suitable construction and repair projects.
Choosing the Right Concrete Pumping Equipment
Before selecting concrete pumping equipment, contractors should consider the material being pumped, required output, pumping pressure, discharge size, power source, transportation requirements, and job-site conditions.
The D3522 provides a 2-inch discharge and variable output, while its trailer and skid configurations offer flexibility for different applications.
Material compatibility should always be confirmed before operation. Contractors should also follow the manufacturer's operating recommendations and equipment requirements.
