Finding the right hydraulic concrete pump for sale can make a significant difference for contractors working on concrete repair, block fill, epoxy, plaster, and stucco applications. The D3522 Pump is a compact 2-inch hydraulic squeeze pump designed for suitable construction and repair materials.
With variable output from 0 to 6 cubic yards per hour, pumping pressure up to 400 PSI, and several power and mounting configurations, the D3522 is an option for contractors searching for a 2-inch concrete pump for sale.
D3522 Hydraulic Concrete Pump for Sale
The D3522 is a compact 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox. It is designed for applications including concrete repair, epoxy, block fill, plaster, and stucco.
The machine can be supplied as a trailer-mounted pump or a lower-profile skid-mounted pump, providing flexibility for different transportation and job-site requirements.
For contractors comparing a hydraulic concrete pump for sale, the D3522 combines variable-speed operation with a compact pumping configuration.
What Makes the D3522 a 2-Inch Concrete Pump?
The D3522 uses a 2-inch hydraulic squeeze pumping system with a 2-inch HD discharge. The variable-speed system allows output to be adjusted between 0 and 6 cubic yards per hour.
The pump provides up to 400 PSI pumping pressure, according to the supplied specifications.
This combination of discharge size, pressure, and variable output makes the D3522 suitable for various compatible construction and repair applications.
Key Features of the D3522 Pump
2-Inch Hydraulic Squeeze Pump
The D3522 features a 2-inch hydraulic squeeze pump powered by a heavy-duty planetary gearbox.
Variable-Speed Output
The pump provides an output range of 0–6 cubic yards per hour, allowing operators to adjust material delivery according to project requirements.
400 PSI Pumping Pressure
The D3522 provides pumping pressure of up to 400 PSI based on the supplied specifications.
6 Cubic Foot Receiving Hopper
A 6 cubic foot receiving hopper provides material capacity before the material enters the pumping system.
Trailer or Skid Configuration
The machine can be supplied as a trailer-mounted unit or a lower-profile skid-mounted machine, allowing contractors to choose a configuration appropriate for their job site.
Applications of the D3522 Hydraulic Pump
The D3522 is designed for multiple applications involving compatible materials.
Concrete Repair
The pump can support suitable concrete repair applications requiring controlled pumping of compatible repair materials.
Block Fill
The D3522 can be used for appropriate block fill applications in masonry and construction projects.
Epoxy Applications
The machine can support suitable epoxy pumping applications when the material is compatible with the pumping system.
Plaster and Stucco
The D3522 is also designed for various plaster and stucco applications.
D3522 Pump Specifications
Specification Details
Pump 2" D3522 Hydraulic Squeeze Pump
Pumping Pressure 400 PSI
Output 0–6 Cubic Yards Per Hour
Discharge 2" HD
Hopper 6 cu. ft.
Trailer Single 6,000 lb. capacity axle with electric braking and lights
Dimensions 166" × 88" × 54"
Weight 2,800 lbs.
Power Options
When comparing a hydraulic concrete pump for sale, the available power source is an important consideration. The D3522 offers three power options:
Kubota water-cooled diesel
24 HP Honda gasoline engine
10 HP electric motor
This range gives contractors flexibility when selecting equipment for different operating environments.
D3522 Pump Options
The D3522 can also be configured with several additional options:
Hydraulic receiving hopper agitator
Pendant or wireless remote
Spare tire mounted
Skid mounted with forklift tubing
Hydraulic pressure washer
Air compressor mounted
These options can help contractors configure the 2-inch concrete pump for sale according to specific job-site requirements.
Trailer-Mounted 2-Inch Concrete Pump
The trailer-mounted D3522 provides a mobile pumping solution for contractors who need to transport equipment between job sites.
The trailer configuration includes a single 6,000 lb. capacity axle with electric braking and lights, according to the supplied specifications.
Skid-Mounted D3522 Pump
For applications where a trailer-mounted pump is not preferred, the D3522 can be supplied in a lower-profile skid-mounted configuration.
The skid option can include forklift tubing, helping provide flexibility for equipment handling and positioning.
Benefits of a Hydraulic Concrete Pump
A hydraulic pumping system can provide controlled material delivery for suitable construction and repair applications. The D3522 combines hydraulic squeeze pumping with variable-speed operation.
Important characteristics include:
Compact 2-inch pumping system
Variable output up to 6 cubic yards per hour
Up to 400 PSI pumping pressure
6 cubic foot hopper
Multiple power options
Trailer or skid-mounted configurations
Suitable applications for concrete repair, block fill, epoxy, plaster, and stucco
How to Choose a 2-Inch Concrete Pump for Sale
Before purchasing a 2-inch concrete pump for sale, contractors should consider:
Material compatibility – Verify that the material is suitable for the pump.
Required output – Determine the project's required pumping rate.
Discharge size – Confirm that a 2-inch discharge meets the application requirements.
Pumping pressure – Compare the required pressure with the pump's capabilities.
Power source – Select diesel, gasoline, or electric power based on the job site.
Mounting configuration – Choose trailer-mounted or skid-mounted equipment.
Job-site conditions – Consider transportation, access, and equipment positioning.
The D3522 offers variable output from 0–6 cubic yards per hour, but the correct configuration should always be determined based on the specific material and application.
D3522 Pump for Construction and Repair
The D3522 is designed as a compact pumping solution for contractors working with suitable concrete repair, epoxy, block fill, plaster, and stucco materials.
Its 2-inch hydraulic squeeze pump, variable output, multiple power options, and trailer or skid configurations provide flexibility for different construction environments.
If you are searching for a hydraulic concrete pump for sale or a 2-inch concrete pump for sale, the D3522 can be evaluated based on your project's material, output, pressure, and configuration requirements.
Hydraulic Concrete Pump for Sale: 2-Inch Concrete Pump for Sale D3522 Pump
