Finding the right hydraulic squeeze pump supplier is important for contractors who need dependable construction pump equipment for concrete repair and material placement. The Blastcrete D3522 Pump is a compact 2-inch hydraulic squeeze pump designed for applications including concrete repair, epoxy, block fill, plaster, and stucco.
With variable output from 0 to 6 cubic yards per hour, the D3522 provides flexible pumping performance in a compact machine.
D3522 Hydraulic Squeeze Pump Overview
The D3522 is a 2-inch hydraulic squeeze pump driven by a heavy-duty planetary gearbox. It is designed to provide practical pumping performance while remaining suitable for a variety of construction and repair jobsites.
The machine can be configured as either a trailer-mounted pump or a lower-profile skid-mounted unit.
Key Features
2-inch D3522 hydraulic squeeze pump
Variable output from 0–6 cubic yards per hour
Pumping pressure up to 400 PSI
6 cubic foot receiving hopper
Heavy-duty planetary gearbox
Trailer or skid-mounted configuration
Long-lasting pumping tubes
Multiple power options
Optional pendant or wireless remote
D3522 Pump Specifications
Specification Details
Pump 2" D3522 Hydraulic Squeeze Pump
Pumping Pressure 400 PSI
Output 0–6 cubic yards per hour
Discharge 2" HD
Hopper 6 cu. ft.
Trailer Single 6,000 lb. capacity axle
Braking Electric braking and lights
Dimensions 166" × 88" × 54"
Weight 2,800 lbs.
Power Options for Construction Pump Equipment
The D3522 can be supplied with different power configurations to meet various operating requirements.
Kubota Water-Cooled Diesel
A Kubota water-cooled diesel engine is available for contractors who prefer a diesel-powered configuration.
24 HP Honda Gasoline Engine
The D3522 can also be equipped with a 24 HP Honda gasoline engine.
10 HP Electric Motor
A 10 HP electric motor configuration is available for suitable applications where electrical power is accessible.
Applications of the D3522 Pump
As versatile construction pump equipment, the D3522 can be used for several material pumping applications.
Concrete Repair
The compact pump can support various concrete repair projects where controlled material delivery is needed.
Epoxy Applications
The D3522 is suitable for specified epoxy pumping applications and provides variable output for appropriate materials.
Block Fill
The pump can be used for block-fill work and other masonry-related material placement applications.
Plaster and Stucco
The D3522 is also designed for various plaster and stucco applications, providing contractors with one pump for multiple types of work.
Trailer-Mounted and Skid-Mounted Configurations
A major advantage of the D3522 is its configuration flexibility. The trailer version includes a single 6,000 lb. capacity axle with electric braking and lights.
For projects requiring a lower-profile setup, the machine can be supplied as a skid-mounted pump. Forklift tubing can also be included for suitable material-handling requirements.
Available D3522 Options
Depending on project requirements, available options include:
Hydraulic receiving hopper agitator
Pendant or wireless remote
Spare tire mount
Skid mount with forklift tubing
Hydraulic pressure washer
Mounted air compressor
Choosing a Hydraulic Squeeze Pump Supplier
When evaluating a hydraulic squeeze pump supplier, contractors should consider the complete equipment package rather than only the pump itself. Important considerations include:
Required pumping output
Material type and application
Power source
Trailer or skid configuration
Jobsite access
Optional accessories
Equipment availability
Quotation and technical support
A properly configured D3522 can provide a practical solution for contractors handling a variety of concrete and construction repair applications.
The D3522 Pump is compact construction pump equipment designed around a 2-inch hydraulic squeeze pumping system. Its 0–6 cubic yards per hour variable output, 400 PSI pumping pressure, multiple power choices, and trailer or skid-mounted configurations make it suitable for concrete repair, epoxy, block fill, plaster, and stucco applications.
For contractors comparing hydraulic squeeze pump suppliers, the D3522 provides a flexible equipment option that can be configured around different jobsite and application requirements.
