Contractors working on gunite, shotcrete, concrete rehabilitation, and related construction projects need equipment that provides dependable material delivery and precise output control. The Blastcrete H 020 Gunite Machine Attachment is a compact hydraulic rotary gunite attachment designed for variable-speed operation and flexible installation.
For contractors looking for Hydraulic Gunite Equipment or a Portable Gunite Machine, the H 020 offers a practical solution that can connect to a compatible hydraulic power unit.
Blastcrete H 020 Gunite Machine Attachment
The Blastcrete Model H 020 is a hydraulic rotary gunite machine attachment with variable output from 0 to 5 cubic yards per hour. It incorporates the Genuine Piccola single-point clamping system and provides precise control over material output.
The machine requires 10 GPM at 1,500 PSI and is compatible with any hydraulic power unit capable of meeting those requirements. Its hydraulic design also keeps the minimum air requirement to 225 CFM.
Request a Quote
Download the H 020 Brochure
Key Features of the Hydraulic Gunite Equipment
The H 020 is equipped with features intended to simplify operation and equipment handling:
Genuine Piccola Single-Point Clamping System
Precise Material Output Control
Universal Mounting Plate
Forklift Pickup Tubing
Rotor of Your Choice
Variable output from 0–5 cubic yards per hour
Portable Gunite Machine Specifications
Specification H 020
Air Requirement 225 CFM minimum
Output 0–5 cubic yards per hour
Outlet 1.5 inches
Maximum Aggregate ¾ inch
Mounting Skid mount
Hydraulic Requirement 10 GPM @ 1,500 PSI
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Flexible Hydraulic Power
One of the important advantages of the H 020 is its hydraulic power configuration. Instead of requiring a dedicated power source built into the attachment, the machine can utilize a hydraulic power unit that supplies 10 GPM at 1,500 PSI.
This configuration can be useful for contractors who already have compatible hydraulic equipment available at the jobsite.
Material Output Control
Gunite applications can require different production rates depending on the project and material. The H 020 provides variable output from 0 to 5 cubic yards per hour, allowing operators to select an appropriate production rate for the work.
The Genuine Piccola single-point clamping system and precise material output control further support practical operation in demanding construction environments.
Easy Equipment Handling
The H 020 has a compact footprint of 34 × 34 × 50 inches and weighs approximately 1,250 pounds. Forklift pickup tubing is incorporated into the design to assist with moving and positioning the attachment.
For contractors evaluating Portable Gunite Machine options, the compact dimensions and forklift handling provisions can be valuable when equipment must be repositioned around a jobsite.
Applications for Gunite and Shotcrete Work
The H 020 is designed as a hydraulic rotary gunite machine attachment for appropriate dry-mix material applications. Its 1.5-inch outlet and ¾-inch maximum aggregate specification should be considered when matching the machine to project materials.
Potential applications can include suitable gunite, shotcrete, concrete repair, rehabilitation, and other material-spraying projects where the machine's specifications meet the job requirements.
Why Choose the H 020 Gunite Machine Attachment?
Contractors comparing Hydraulic Gunite Equipment can evaluate the H 020 based on several practical characteristics:
Variable production from 0–5 cubic yards per hour
Hydraulic operation
10 GPM @ 1,500 PSI hydraulic requirement
225 CFM minimum air requirement
Compact skid-mounted design
Universal mounting plate
Precise material output control
Genuine Piccola single-point clamping system
Forklift pickup tubing
Hydraulic Gunite Equipment: Portable Gunite Machine for Professional Applications
