Choosing the right Shotcrete Gunite Equipment is important for contractors who need controlled material delivery, reliable operation, and flexibility on demanding concrete spraying projects. The Blastcrete Model H 020 is a hydraulic rotary Gunite Machine Attachment designed to provide variable-speed material output from 0 to 5 cubic yards per hour.
Its compact skid-mounted design and universal mounting plate make the H 020 a practical option for applications requiring hydraulic gunite equipment.
What Is the Blastcrete H 020?
The Blastcrete H 020 is a hydraulic rotary gunite machine attachment featuring a Genuine Piccola single-point clamping system. The machine provides precise material output control and can operate with a hydraulic power unit supplying 10 GPM at 1,500 PSI.
Unlike systems that depend on large amounts of air for material movement, the hydraulic design has a minimum air requirement of 225 CFM.
Key Features of the Gunite Machine Attachment
The H 020 includes features designed to support efficient shotcrete and gunite operations:
Variable output: 0–5 cubic yards per hour
Genuine Piccola single-point clamping system
Precise material output control
Universal mounting plate
Forklift pickup tubing
Choice of rotor
Skid-mounted configuration
These features can help contractors configure the machine according to their specific project and material-handling requirements.
H 020 Technical Specifications
Specification H 020
Machine Type Hydraulic rotary gunite machine attachment
Air Requirement 225 CFM minimum
Output 0–5 cubic yards/hour
Outlet 1.5 inches
Maximum Aggregate ¾ inch
Mounting Skid mount
Hydraulic Requirement 10 GPM @ 1,500 PSI
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Benefits of Hydraulic Shotcrete Gunite Equipment
Hydraulic operation gives operators control over the material output rate, which can be useful when application requirements change during a project. The H 020's variable-speed capability allows output to be adjusted between zero and its maximum rated capacity.
The compact skid-mounted configuration can also simplify equipment integration and handling. Before purchasing or operating the machine, contractors should verify that their hydraulic power unit and air supply meet the manufacturer's stated requirements.
Applications
The H 020 can be considered for construction projects requiring gunite or shotcrete-style material spraying. Its 1.5-inch outlet and maximum aggregate specification should be matched with the intended material and application.
For contractors seeking Shotcrete Gunite Equipment, the H 020 provides a combination of hydraulic operation, adjustable output, and compact equipment dimensions.
Shotcrete Gunite Equipment: Understanding the Blastcrete H 020
