Mining, ground-support, and slope stabilization projects can require reliable equipment for controlled placement of cementitious materials. The Blastcrete Model H 020 is a hydraulic rotary Gunite Machine Attachment designed for variable material output from 0 to 5 cubic yards per hour.
For contractors evaluating Gunite Equipment for Mining or Gunite Equipment for Slope Stabilization, the H 020 offers a compact skid-mounted configuration, precise output control, and compatibility with a suitable hydraulic power unit.
Gunite Equipment for Mining Applications
Gunite and shotcrete techniques can be used in appropriate mining and underground construction applications where sprayed material is required. The H 020 provides variable-speed output, allowing operators to control material delivery within its rated capacity.
The machine requires 10 GPM at 1,500 PSI of hydraulic power and has a minimum air requirement of 225 CFM.
Before using the equipment in a mining environment, contractors should verify that its specifications, materials, ventilation requirements, and safety controls are suitable for the specific site and application.
Gunite Equipment for Slope Stabilization
Slope stabilization projects can involve placing cementitious material over prepared surfaces to create suitable protective or structural layers. A variable-speed gunite machine can provide controlled material delivery for appropriate applications.
The H 020's precise material output control allows the operator to adjust the delivery rate within the machine's 0–5 cubic-yard-per-hour range.
Key Features of the H 020
The Blastcrete H 020 includes:
Variable output from 0–5 cubic yards per hour
Genuine Piccola single-point clamping system
Precise material output control
Universal mounting plate
Forklift pickup tubing
Rotor selection
Skid-mounted configuration
These features provide flexibility when configuring the Gunite Machine Attachment for compatible jobsite requirements.
H 020 Technical Specifications
Specification Details
Machine Type Hydraulic rotary gunite machine attachment
Output 0–5 cubic yards/hour
Air Requirement 225 CFM minimum
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5 inches
Maximum Aggregate ¾ inch
Mounting Skid mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Compact Hydraulic Gunite Design
The H 020 measures 34 × 34 × 50 inches and weighs approximately 1,250 pounds. Forklift pickup tubing is included to facilitate handling and positioning.
Its universal mounting plate allows the attachment to be configured with compatible equipment, while the hydraulic drive provides variable-speed control.
What to Consider Before Selecting Gunite Equipment
When choosing Gunite Equipment for Mining or Gunite Equipment for Slope Stabilization, contractors should evaluate:
Required material output.
Maximum aggregate size.
Available hydraulic power.
Required air capacity.
Equipment dimensions and handling requirements.
Compatibility with the intended material.
Site-specific operating and safety requirements.
Gunite Equipment for Mining and Slope Stabilization
