MX-10 Mixer / Pump: Advanced Thermal Insulation Concrete Equipment for Industrial Refractory Applications

MX-10 Mixer / Pump – High-Performance Thermal Insulation Concrete Equipment

Industrial facilities rely on thermal insulation and refractory systems to improve energy efficiency, protect equipment from extreme temperatures, and extend the lifespan of critical assets. Choosing dependable thermal insulation concrete equipment is essential for achieving consistent material placement and high-quality installations. The MX-10 Mixer / Pump is designed to deliver exceptional performance for dense refractory shotcrete and pump cast applications, making it an ideal solution for demanding industrial environments.

Since 1996, the MX-10 has established itself as the industry standard for monolithic refractory installations. Combining a high-torque hydraulic pan mixer with an ultra-high-pressure swing tube piston pump, it provides reliable mixing, efficient pumping, and consistent results for thermal insulation and refractory projects.

Engineered for Thermal Insulation Applications

The MX-10 is suitable for a wide variety of industrial insulation and refractory installation projects, including:

Furnace insulation systems
Boiler refractory and insulation lining
Cement kiln thermal insulation
Power plant refractory maintenance
Petrochemical processing equipment
Industrial incinerators
Steel mill furnace linings
Mining and mineral processing facilities

Its capability to pump dense refractory materials more than 300 feet vertically makes it ideal for large industrial plants where elevated installation points and difficult access are common.

Powerful Mixing and Pumping Performance

The MX-10 combines a 2,200 lb. capacity hydraulic pan mixer with a 3-inch × 24-inch ultra-high-pressure swing tube piston pump capable of generating 2,200 PSI piston face pressure. This combination delivers homogeneous refractory mixes while maintaining consistent pumping performance.

With production rates of up to 10 tons per hour and a rapid 1.5 to 2-minute mixing cycle, the MX-10 helps contractors complete thermal insulation and refractory installations efficiently while minimizing project downtime.

Features Designed for Maximum Productivity

The MX-10 is engineered to improve jobsite efficiency while simplifying maintenance.

High-Performance Features
2,200 PSI piston face pressure
3-inch ultra-high-pressure swing tube pump
2,200 lb. hydraulic pan mixer
Output up to 12 cubic yards per hour
Reliable solid-state electronic controls
CE Certified design
Easy Maintenance Features

Routine cleaning and servicing are simplified with:

Swing-out receiving hopper for quick access
Easy access to the swing tube section
Forklift tubing for convenient flat-pack removal
Hydraulic hopper agitator for continuous material flow
Fill Rite water meter for accurate water measurement
20-gallon dousing bucket for fast water introduction

These features help reduce maintenance time while improving equipment availability.

Flexible Power Options

The MX-10 is available with multiple power configurations to meet different operating environments:

John Deere 4045T 99 HP water-cooled diesel engine
Deutz BF4M 2012 102 HP water-cooled diesel engine
Dual 40 HP electric motors

These options provide flexibility for indoor industrial facilities and outdoor maintenance projects.

Optional Equipment

Enhance performance with optional accessories including:

2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Wireless remote control
Pendant remote control
Spare tire mount
Skid-mounted configuration with forklift tubing
MX-10 Technical Specifications
Specification Details
Pump 3" × 24" Ultra High Pressure Swing Tube
Pump Pressure 2,200 PSI
Mixer 2,200 lb. Hydraulic Pan Mixer
Output 0–12 Cubic Yards Per Hour
Discharge 3"
Hopper 2,500 lb. Swing-Out Receiving Hopper with Hydraulic Agitator
Operating Platform 22 sq. ft.
Crane Pickup Central Four-Point Pickup (No Spreader Bar Required)
Electrical Controls Solid State Valve Control
Trailer Dual 6,000 lb. Capacity Axles with Electric Brakes and Lights
Dimensions 204" × 88" × 117"
Weight 9,000 lbs.
Why Choose the MX-10 Thermal Insulation Concrete Equipment?

The MX-10 is trusted by refractory contractors and industrial maintenance professionals because it combines high output, reliable operation, and durable construction.

Key advantages include:

Pumps dense refractory materials more than 300 feet vertically
Produces up to 10 tons of material per hour
Fast 1.5–2 minute mixing cycles
Ideal for refractory shotcrete and pump cast applications
Easy maintenance with swing-out hopper access
Rugged design for demanding industrial environments
Proven industry performance since 1996
Excellent return on investment
Improve Thermal Insulation Projects with the MX-10 Mixer / Pump

Selecting the right thermal insulation concrete equipment is essential for improving installation quality, reducing maintenance downtime, and maximizing the performance of high-temperature industrial systems. The MX-10 Mixer / Pump combines powerful hydraulic mixing, ultra-high-pressure pumping, and user-friendly design to deliver reliable results across a wide range of refractory and thermal insulation applications.

Whether working on furnaces, boilers, kilns, power plants, or other industrial processing equipment, the MX-10 provides the productivity, durability, and efficiency required for successful thermal insulation and refractory installation projects.
