Industrial Mortar Pump and Diesel Mixer Pump Solution – RMX-5000 Mixer / Pump
For demanding construction, refractory, and industrial applications, choosing the right Industrial Mortar Pump and Diesel Mixer Pump is essential for achieving reliable material flow, high productivity, and long service life. The RMX-5000 Mixer / Pump is a heavy-duty pumping and mixing system engineered for contractors who require powerful performance in challenging job site conditions.
The RMX-5000 combines an ultra-high-pressure swing tube pump with advanced hydraulic mixing technology, making it suitable for refractory materials, shotcrete, plaster, stucco, and dense conventional concrete applications.
RMX-5000 Industrial Mortar Pump Features
The RMX-5000 is designed to deliver consistent performance for industrial pumping operations where reliability and power are critical.
2200 PSI High-Pressure Pumping Capability
The RMX-5000 features a 2200 PSI piston face pressure system designed for refractory shotcrete and dense conventional shotcrete applications. This high-pressure design allows materials to be pumped efficiently over long distances while maintaining smooth operation.
Heavy-Duty 1000 lb Paddle Mixer
For refractory applications, the machine includes a 1000 lb capacity hydraulic paddle mixer equipped with a planetary gearbox drive. This system provides powerful mixing performance and helps maintain uniform material consistency.
1000 lb Spiral Mixer for Versatile Applications
The integrated 1000 lb capacity hydraulic spiral mixer supports conventional shotcrete and plaster applications, providing flexibility for different construction materials and project requirements.
Hydraulic Receiving Hopper Lift
The hydraulic receiving hopper lift allows easy access to the swing tube section for cleaning and maintenance. This design helps improve service efficiency and reduces equipment downtime.
Reliable Industrial Design
Additional RMX-5000 features include:
Fill Rite water meter for accurate water measurement
Convenient 3-inch HD side discharge
Reliable solid-state electronics
CE certification for quality and safety standards
RMX-5000 Diesel Mixer Pump Specifications
Pump System
Pump Type: 3" x 18" Ultra High Pressure Swing Tube
Pump Pressure: 2,200 PSI
Mixer System
Paddle Mixer Capacity: 1,000 lb hydraulic paddle mixer for refractory applications
Spiral Mixer Capacity: 1,000 lb hydraulic spiral mixer for shotcrete and plaster applications
Output Performance
Output Range: 0–5 cubic yards per hour
Hopper and Discharge
Discharge Size: 3-inch side discharge
Hopper Capacity: 1,200 lb receiving hopper with hydraulic agitator
Trailer and Dimensions
Trailer Capacity: Single 6,000 lb axle with electric braking and lights
Dimensions: 165" x 76" x 63"
Weight: Approximately 5,000 lbs
Diesel Power Options for Industrial Applications
The RMX-5000 is available with a powerful diesel engine option designed for demanding construction environments.
Kubota Diesel Engine Configuration
Kubota V3600
66 HP water-cooled diesel engine
This diesel-powered setup provides excellent mobility and dependable operation for remote job sites where electrical power may not be available.
Electric Motor Option
50 HP electric motor configuration
The electric option is suitable for stationary industrial installations and projects with available electrical power.
Optional Equipment
The RMX-5000 can be customized with additional accessories to improve productivity and convenience:
2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
150-gallon water tank with 2-inch flow meter
Spare tire mounting
Pendant or wireless remote control
Skid-mounted design with forklift tubing
Applications of the RMX-5000 Industrial Mortar Pump
The RMX-5000 Diesel Mixer Pump is suitable for various industries and applications, including:
Industrial mortar pumping
Refractory installation projects
Shotcrete applications
Tunnel construction
Mining operations
Concrete repair work
Plaster and stucco spraying
Heavy-duty construction projects
Why Choose the RMX-5000 Mixer / Pump?
A professional Industrial Mortar Pump requires dependable pumping pressure, strong mixing capability, and easy maintenance. The RMX-5000 provides a complete solution by combining a high-pressure pump system, large-capacity mixer, hydraulic controls, and durable diesel power options.
Industrial Mortar Pump and Diesel Mixer Pump Solution RMX-5000 Mixer / Pump
