25 Ton Per Hour Mixer and 25 TPH Refractory Pump: MX-20CM

The Blastcrete MX-20CM is a high-capacity mixer/pump designed for demanding refractory placement applications. With a stated mixer and pump capacity of up to 25 tons per hour, the MX-20CM provides an integrated solution for mixing, hydrating, and pumping refractory materials.

For contractors searching for a 25 ton per hour mixer or 25 TPH refractory pump, the MX-20CM combines a high-shear continuous mixer with a 4-inch high-pressure swing tube piston pump in one machine.

High-Capacity 25 Ton Per Hour Mixer

The MX-20CM features a compact, two-stage mixing system.

The primary stage uses a high-shear continuous mixer to hydrate the material. A secondary medium-shear mixer is mounted in the receiving hopper before the material enters the pump.

The mixer has a stated output of 0–25 tons per hour, making it suitable for both smaller refractory installations and high-volume production requirements.

Two-Stage Mixing Process

The material moves through the system in the following sequence:

Material Charging → High-Shear Continuous Mixer → Secondary Mixer → Receiving Hopper → Swing Tube Piston Pump → Refractory Placement

This integrated design reduces the need for separate mixing and pumping equipment.

25 TPH Refractory Pump

The MX-20CM incorporates a 4" x 36" ultra-high-pressure swing tube piston pump.

The pump is rated for:

Output: 0–25 tons per hour
Piston face pressure: 2,200 PSI
Pump size: 4" x 36"
Receiving hopper: 1,500 lb capacity
Hydraulic hopper agitator

The pump is designed for rugged refractory pump-cast and shotcrete applications.

For projects requiring high material throughput, the stated 25 TPH capacity provides the production capability associated with high-volume refractory installation.

Designed for Different Production Requirements

Not every refractory project requires maximum output. The MX-20CM is designed to accommodate a broad range of installation sizes.

For smaller installations, the machine can operate at approximately 2–3 tons per hour. At higher production requirements, the mixer and pump are rated up to 25 tons per hour.

This gives refractory contractors flexibility when moving between maintenance work, repair projects, and larger industrial installations.

High-Shear Continuous Mixer

A major feature of the MX-20CM is its high-shear continuous mixer.

The mixer is designed to hydrate the material continuously before it reaches the secondary mixing stage. Its stated maximum output is 25 tons per hour.

The two-stage design helps integrate mixing and pumping into a single workflow rather than requiring separate machines for material preparation and delivery.

High-Pressure Swing Tube Pump

The pumping system uses a swing tube piston design with oversized differential cylinders.

The MX-20CM has a stated piston face pressure of 2,200 PSI, while the hydraulic pressure required to operate the pump is comparatively lower because of the oversized differential cylinders.

The swing tube system is designed for demanding refractory pump-cast and shotcrete applications.

Easy Access for Cleaning and Maintenance

The MX-20CM features a swing-out receiving hopper that provides access to the swing tube section.

This design can simplify:

Pump cleaning
Routine inspection
Maintenance
Material removal
Access to the swing tube section

The lower hopper also includes forklift tubing to facilitate flat-pack removal.

Reduced Dust and Cleanup

The MX-20CM is designed to minimize dust generated while charging the continuous mixer.

The supplied machine information also states that cleanup of the continuous mixer is quicker and produces very little waste.

These characteristics can be particularly useful for contractors performing repeated refractory installations where equipment turnaround and cleanup are important considerations.

MX-20CM Specifications
Specification MX-20CM
Mixer High-Shear Continuous Mixer
Mixer Output 0–25 tons/hour
Pump 4" x 36" Ultra High Pressure Swing Tube Pump
Pump Output 0–25 tons/hour
Piston Face Pressure 2,200 PSI
Dry Hopper 3,000 lb capacity
Receiving Hopper 1,500 lb capacity
Hopper Agitator Hydraulic
Flow Meter 0–20 gallons
Crane Pickup Four-point pickup
Trailer Dual 6,000 lb capacity axles
Dimensions 220" x 89" x 108"
Weight 7,500 lb
Certification CE
Power Options

The 25 ton per hour mixer and pump is available with several power configurations:

99 HP John Deere water-cooled diesel
102 HP Deutz water-cooled diesel
Dual electric motors

The supplied specifications indicate approximately 100 HP is required for the machine.

The manufacturer information also states that the two-stage mixer and oversized differential design can reduce fuel consumption by 50% compared with competitive machines. Actual fuel consumption will vary according to operating conditions, material, workload, and configuration.

Features of the 25 TPH Refractory Pump

Key MX-20CM features include:

Up to 25 tons/hour pump output
Up to 25 tons/hour mixer output
4" x 36" swing tube piston pump
2,200 PSI piston face pressure
High-shear continuous mixer
Secondary medium-shear mixer
3,000 lb dry hopper
1,500 lb receiving hopper
Hydraulic receiving-hopper agitator
0–20 gallon flow meter
Solid-state electronic controls
Swing-out receiving hopper
Four-point crane pickup
CE certification
Dual trailer axles with electric brakes
Optional Equipment

The MX-20CM can also be configured with several options:

2,000 PSI hydraulic pressure washer
Vogel automatic lubrication system
Mounted spare tire
Pendant remote
Skid-mounted configuration
Forklift tubing

These options provide additional flexibility for cleaning, maintenance, transportation, and jobsite operation.

7,500-Pound Towing Weight

The MX-20CM has a stated towing weight of 7,500 pounds.

Its trailer incorporates dual 6,000-pound-capacity axles with electric braking and lights. The machine also provides a four-point crane pickup without requiring a spreader bar, according to the supplied specifications.

The supplied information states that no special license is needed to tow the machine; operators should verify applicable local transportation and towing regulations before moving the equipment on public roads.

Applications for the MX-20CM

The MX-20CM can be used for suitable refractory pump-cast and shotcrete applications, including projects involving:

Industrial refractory placement
Furnace maintenance
Kiln lining and repair
Boiler refractory work
Steel plant maintenance
Foundry applications
Industrial furnace lining
Refractory repair
High-volume refractory installation
Shotcrete applications

Actual suitability depends on the refractory material, mix design, installation method, pumping distance, hose configuration, and jobsite requirements.

Why Choose a 25 Ton Per Hour Mixer?

A 25 ton per hour mixer can provide substantial production capacity for contractors handling large refractory projects.

The MX-20CM combines this mixing capacity with a matching 25 TPH refractory pump, allowing the material preparation and pumping processes to work as one integrated system.

Instead of using separate equipment for continuous mixing and pumping, the MX-20CM combines both functions into a single machine.

The Blastcrete MX-20CM is designed for contractors requiring high-capacity refractory mixing and pumping equipment. Its 0–25 tons/hour high-shear continuous mixer and 0–25 tons/hour swing tube piston pump provide a stated maximum production capacity of 25 tons per hour.

With its two-stage mixing system, 2,200 PSI piston face pressure, swing-out receiving hopper, multiple power options, and transportable trailer configuration, the MX-20CM is a practical solution for demanding refractory placement and suitable shotcrete applications.

If you are researching a 25 ton per hour mixer, 25 TPH refractory pump, or integrated refractory mixer/pump, the MX-20CM offers a high-capacity configuration built around continuous mixing and high-pressure piston pumping.
