A dependable Gunite Spraying Machine can help contractors achieve controlled material placement for suitable gunite and shotcrete applications. The Blastcrete Model H 020 is a hydraulic rotary Gunite Shotcrete Machine attachment designed with variable-speed operation and precise material output control.
With an output range of 0–5 cubic yards per hour, the H 020 provides adjustable material delivery in a compact skid-mounted configuration.
H 020 Gunite Machine Attachment
The Blastcrete H 020 is a hydraulic rotary Gunite Machine Attachment featuring a Genuine Piccola single-point clamping system. This system is designed for straightforward operation while helping provide consistent control over material output.
The attachment requires 10 GPM at 1,500 PSI of hydraulic power and is compatible with a hydraulic power unit capable of supplying this capacity. Because the H 020 is hydraulically powered, its minimum air requirement is 225 CFM.
Key Features of the Gunite Spraying Machine
The H 020 includes:
Genuine Piccola single-point clamping system
Precise material output control
Universal mounting plate
Forklift pickup tubing
Rotor of your choice
Variable-speed operation
Skid-mounted configuration
These features provide contractors with a flexible Gunite Spraying Machine configuration for suitable construction and material-placement applications.
Variable-Speed Gunite Shotcrete Machine
The H 020 provides variable output from 0 to 5 cubic yards per hour. Variable-speed operation allows operators to adjust material delivery according to the requirements of the project and application.
Precise material output control is particularly valuable when consistent material placement is required.
Hydraulic and Air Requirements
The H 020 uses hydraulic power with the following requirements:
Hydraulic flow: 10 GPM
Hydraulic pressure: 1,500 PSI
Minimum air requirement: 225 CFM
The manufacturer states that the machine is universal with any hydraulic power unit capable of providing the specified hydraulic capacity.
H 020 Specifications
Specification H 020
Machine Type Hydraulic rotary gunite machine attachment
Output 0–5 cubic yards/hour
Air Requirement 225 CFM minimum
Hydraulic Requirement 10 GPM @ 1,500 PSI
Outlet 1.5"
Maximum Aggregate ¾"
Mounting Skid mount
Estimated Wear Pad Life 200 tons
Dimensions 34" × 34" × 50"
Weight 1,250 lbs.
Compact Design for Gunite Applications
The H 020 features a universal mounting plate and forklift pickup tubing. Its skid-mounted configuration provides a compact equipment solution while allowing convenient handling and integration with compatible hydraulic equipment.
The rotor-of-your-choice option provides additional configuration flexibility for contractors selecting a Gunite Shotcrete Machine for their specific requirements.
Why Choose the H 020 Gunite Machine Attachment?
The H 020 offers a combination of compact construction and controlled output, including:
0–5 cubic yards per hour variable output
Precise material output control
Hydraulic operation
225 CFM minimum air requirement
1.5-inch outlet
Maximum ¾-inch aggregate
Universal mounting plate
Genuine Piccola single-point clamping system
Skid-mounted design
